Denon AVR-S700W Service Manual

MAIN
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C5508 13405014940AS CAP,ELECT(63V/100uF) CCEA1JH101T 1
C5509 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5510 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5511 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5513 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5607 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5608 13405014940AS CAP,ELECT(63V/100uF) CCEA1JH101T 1
C5609 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5610 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5611 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5613 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5707 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5708 13405014940AS CAP,ELECT(63V/100uF) CCEA1JH101T 1
C5709 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5710 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5711 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5713 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5801 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5802 nsp CAP,ELECT(6.3V/470uF) CCEA0JH471T 1
C5803 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5804 nsp CAP,ELECT(6.3V/470uF) CCEA0JH471T 1
C5805 nsp CAP,ELECT(16V/47uF) CCEA1CH470T 1
C5806 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC 1
C5807 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5808 943134010480S CAP,ELECT(100V/100uF) CCEA2AH101E 1
C5809 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5810,5811 943134503010S CAP,ELECT(35X45)WITHOUTPLATEONTHETOP CCET67VPKPO103
N
2*
C5812,5813 90M-OF100490R CAP,METALPEFILM(250V/0.1uF) KCME2E104JP04T 2
C5816 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5817,5818 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C5819 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C5820 nsp CAP,ELECT(100V/1uF),85'CBlack CCEA2AH1R0T 1
C5821 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C5823 nsp CAP,CHIP(1608,50V/10pF,C0G)_SAMSUNG CCUS1H100JAS 1
C5825,5826 nsp CAP,ELECT(100V/1uF),85'CBlack CCEA2AH1R0T 2
C5827 nsp CAP,MYLAR(50V/0.01uF/J) HCQI1H103JZT 1
OTHER PARTS GROUP
BK505 nsp BRACKET,PCB CMD1A569-V1 1
BK506 nsp BRACKET,PCB CMD1A629 1
BN501 nsp WIREASS'YLocking(YH)(9P,2MM,150MM,#26) CWB1B009150HC 1
BN502 nsp WIREASS'YLocking(YH)(8P,2MM,150MM,#26) CWB1B008150HC 1
BN503 nsp WIREASS'YLocking(YH)(3P,2MM,200MM,#26) CWB4B003200HC 1
CN502 nsp WAFER,7P(DIP,3.96PITCH) CJP07GA90ZY 1
CN508 nsp PINHEADER(09P,1.25mm,STRAIGHT,B-TO-B) CJP09GI281Z 1
CN510 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN51B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN520 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN52B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN530 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN53B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN540 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN54B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN550 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN55B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN560 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN56B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN570 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN57B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
ET502 nsp PLATE,EARTH(TRONICELECTRONICS) CJT1A026 1
F5801,5802 nsp HOLDER,FUSE KJCFC5S 2
JK501-507 943643102420S 2P,SCREWSPK(R/B) CJJ5N023Z 7
L5101 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5201 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5301 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5401 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5501 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5601 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5701 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
RY581 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU 1
RY582-585 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU 4
RY586 943682100520S RELAY,942H-2C-12DS,DC12V,2C2P CSL4A022ZU 1 *
TU500 943183100510S TUNER,FM(SCREW:FTYPE),AM,SI4730-D60 E3 CNVYST990-A9U1 1 *
TU500 943183100520S TUNER,RDS,FM(PALTYPE),AM,SI4731-D60 E2/E1 CNVYST990-D8E1 1 *
TU500 943183100500S TUNER,FM(PALTYPE),AM,SI4730-D60 E1C/K CNVYST990-A2J1 1 *
VR510 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T 1
VR520 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T 1
VR530 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T 1
VR540 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T 1
VR550 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T 1
VR560 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T 1
VR570 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T 1
5

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
