Denon AVR-S700W Service Manual

POWER
POWER PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D3001-3004 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 4
D3103,3104 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D3200 943209001080S DIODE,CHIP,SWITCHING X1100E3 CVD1SS355T 1
D6001-6008 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 8
D6009 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D6012 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
D6013 943204500310S DIODE,SchottkyBattier(TO220FN) CVDRBQ30T65A 1
IC301 943232100370S I.C,REGULATOR(+12V,TO220) CVIKIA7812BPI 1
IC302 00D9430183909 I.C,REGULATOR HVIKIA7912PI 1
IC305 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1
! IC601 231010091708S I.C,OFF-LINEPOWERSWITCH CVITOP258MG 1
! IC602 963239010480S I.C,PHOTOCOUPLER CVIPC123Y22FZ0F 1
IC603 212050010508S I.C,SHUNTREGULATOR(TO-92) CVIKIA2431AP 1
Q3001 943215500020S T.R,RT1P141C(10K-10K) X1100E3 CVTRT1P141C 1
Q3002 943214500020S T.R,2SC3052 X1100E3 CVT2SC3052 1
Q6002 943229500110S F.E.T,INK0010AC1(N-CH,SC-59,MOSFET,ISAHAYA) CVTINK0010AC1 1
Q6003 943214500020S T.R,2SC3052 CVT2SC3052 1
ZD608-610 00D2760762958 DIODE,ZENER,1/2W,39V E3/K CVDZJ39BT 3
ZD611-618 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT 8
ZD619 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT 1
ZD620 00D2760762958 DIODE,ZENER,1/2W,39V CVDZJ39BT 1
ZD621 00D9430196306 DIODE,ZENER,1/2W,7.5V E3 CVDZJ7.5BT 1
ZD621 943202000940S DIODE,ZENER,1/2W,16V E2/E1/E1C CVDZJ16BT 1
ZD621 00D9600095607 DIODE,ZENER,1/2W,5.6V K CVDZJ5.6BT 1
RESISTOR GROUP
R3001 nsp RES,CHIP(1608/5%/1Kohm) X1100E3 CRJ10DJ102T 1
R3002 nsp RES,CHIP(1608/5%/3.3Kohm) X1100E3 CRJ10DJ332T 1
R3003 nsp RES,CHIP(1608/5%/2.2Kohm) X1100E3 CRJ10DJ222T 1
R3004 nsp RES,CHIP(1608/5%/100Kohm) X1100E3 CRJ10DJ104T 1
R6004 nsp RES,CARBON(1/5W,330Kohm,J) CRD20TJ334T 1
R6006 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R6008,6009 nsp RES,CARBON(1/5W,2.2Mohm,J) E3/K CRD20TJ225T 2
R6010 nsp RES,CARBON(1/5W,1Mohm,J) E3/K CRD20TJ105T 1
R6011 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R6012 nsp RES,CHIP(1608/5%/270Kohm) E3/K CRJ10DJ274T 1
R6012 nsp RES,CHIP(1608/5%/56Kohm) E2/E1/E1C CRJ10DJ563T 1
R6013 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R6014 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6015 nsp RES,CARBON(1/5W,6.8ohm,J) CRD20TJ6R8T 1
R6016 nsp RES,CARBON(1/5W,56ohm,J) CRD20TJ560T 1
R6017 nsp RES,CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R6018 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R6019 nsp RES,CHIP(1608/1%/22Kohm) CRJ10DF2202T 1
R6022 nsp RES,CHIP(1608/1%/6.8Kohm) CRJ10DF6801T 1
R6024 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R6025 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6027-6030 nsp RES,CHIP(2012/5%/8.2Mohm) CRJ18AJ825T 4
R6031-6033 nsp RES,CHIP(2012/5%/1Mohm) CRJ18AJ105T 3
CAPACIITORS GROUP
C3005 00MOF15104040 CAP,METAL-FILM(100V/0.1uF) CCME2A104JXT 1
C3006 943134010620S CAP,ELECT(25V/4700uF) CCEA1EH472E 1
C3007 00MOA33802520 CAP,ELECT(25V/3300uF) CCEA1EH332E 1
C3008 943134502350S CAP,ELECT(50V/470uF) CCEA1HH471E 1
C3012,3013 943134502350S CAP,ELECT(50V/470uF) CCEA1HH471E 2
C3100 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG X1100E3 CCUS1H102KCS 1
! C6001-6003 963132011940S CAP,CERAMIC
(
X1/Y2,0.01uF,AC250V
)
CCKDKY103MFM 3
C6004 943134501590S CAP,ELECT(200V/100uF),105'C E3/K CCET200NHA101E
S
1
C6004 963134010200S CAP,ELECT(400V/100UF,18X40,NHA) E2/E1/E1C CCET400NHA101E
S
1
C6005 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 1
C6006 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C6007 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6008 00D9430175108 CAP,ELECT(50V/10uF),105'C CCEA1HNXA100TS 1
C6009 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6011 963132010120S CAP,CERAMIC(DC1KV/1000pF) CCKDDEH102KCM 1
C6012 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6013 00MOA47602520 CAP,ELECT(25V/47uF),105'C CCEA1ENXA470TS 1
C6014 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6015 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 1
C6018,6019 963134010220S CAP,ELECT(6.3V/5600uF) CCEA0JNXA562ES 2
C6020 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
! C6023 963132011930S CAP,CERAMIC
(
X1/Y1,2200P,AC250V
)
CCKDKX222MEM 1
C6024 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6026 943132100510S CAP,CHIP(3216,1KV/47pF,X7R) CCUP3A470JA 1 *
OTHER PARTS GROUP
BK301,302 nsp BRACKET,PCB CMD1A569-V1 2
BK303 nsp BRACKET,PCB CMD1A387-V1 1
BK601,602 nsp BRACKET,PCBM3 CMD1A834 2
BK603 nsp BRACKET,PCB CMD1A629 1
BN301 nsp WIREASS'YLocking(7P,2.5MM,80MM,#24) CWB1C0070803D 1
BN302 nsp WIREASS'YLocking(YH)(3P,2MM,50MM,#28) X1100E3 CWB1A003050HC 1
BN601 nsp WIREASS'YLocking(YH)(5P,2.5MM,150MM,#22) CWB1D0051503D 1
CN302 nsp WAFER/STRAIGHT/2.5mm/5P CJP05GA01ZY 1
CN601 nsp WAFER,2P,3.96mm CJP02KA060ZY 1
CN602 nsp WAFER,2P,7.92mm CJP02GA89ZY 1
! CX601 943139500020S CAP,POLYPROPYLENEFILM HCQF2E104KZE 1
! CY601,602 963134011730S CAP,CERAMIC
(
X1/Y1,470P,AC250V
)
CCKDKX471KBM 2
F3001,3002 nsp HOLDER,FUSE KJCFC5S 2
F6001,6002 nsp HOLDER,FUSE KJCFC5S 2
JK301 90M-YT004860R JACK,STEREO(BLKMOLD) X1100E3 CJJ2D008Z 1
! LF602 963111010230S LINEFILTER,27mH E3/K CLZ9Z126Z 1
LF602 963134010200S CAP,ELECT(400V/100UF,18X40,NHA) E2/E1/E1C CCET400NHA101E
S
1
! RY601 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1P CSL1C006ZE 1
! T6001 943102100350S TRANS,SWITCHING CLT9Z093ZE 1
! F3001 00D2061096006 FUSE
(
218Series,250V/1.25A
)
KBA2C1250TLE
Y
1
! F3002 00D2061096006 FUSE
(
218Series,250V/1.25A
)
KBA2C1250TLE
Y
1
! F5801 90M-FS001220R FUSE
(
218Series,250V/8A
)
KBA2C8000TLE
Y
1
! F5802 90M-FS001220R FUSE
(
218Series,250V/8A
)
KBA2C8000TLE
Y
1
! F6001 963652010510S FUSE
(
S506Series,250V,2A
)
E3/K CBA2C2000TLEC 1
6

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
