Denon AVR-S700W Service Manual

DIGITAL
DIGITAL PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D7131 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI
1
1
D7201 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30 1
D7401 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D7402 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7403,7404 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 2
D7501 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D7502 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7702-7705 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 4
D8051,8052 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 2
D8201,8202 00D9430196306 DIODE,ZENER,1/2W,7.5V CVDZJ7.5BT 2
D8203,8204 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 2
D8205 943202500720S DIODE,ZENER(3.6V/0.5W,SOD-123) CVDMM1Z3V6H 1
D8206 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D8501,8502 943202500820S DIODE,ZENER(6.8V/0.5W,SOD-123) X1100E3 CVDMM1Z6V8H 2 *
D8801,8802 943202500730S DIODE,ZENER(5.1V/0.5W,SOD-123) CVDMM1Z5V1H 2
IC701 943236101820S I.C,HDMI2.0Transceiver(HQFP-144P) CVIMN8647781A 1 *
IC721 943236012460S I.C,HDMITransceiver(LQFP-144P) CVIADV7623BSTZ 1
IC722 - I.C,SERIALFLASH(32M) CVIMX25L3206EM2I
-
1
IC722┗
943248102660S I.C,OSDSerialFlash
(
AVR-S700WBKE3/X1100WBKE3
)
E3/E1C/K CVIANAM1902AV 1 *
IC722┗
943248102670S I.C,OSDSerialFlash
(
AVR-X1100WBKE2/E1
)
E2/E1 CVIMX25L6406EM2I
-
1*
IC722┗ 943248102680S I.C,OSDSerialFlash(AVR-X1100WBKE1C/SPE1C) E1C CVIANAM1904AV 1 *
IC722┗ 943248102690S I.C,OSDSerialFlash(AVR-X1100W-K) JP CVIANAM1905AV 1 *
IC723 943239101510S I.C,MUX/DEMUX(TSSOP-16P) CVISN74CBT3251P
W
1*
IC731 963236101810S I.C,HDMI2.0Transceiver(HQFP-144P) CVIMN8647781 1 *
IC741-746 943239101070S I.C,DC-DCCONVERTER(3A,QFNT&R-24P) CVIEN5339QI 6
IC747 943239100730S I.C,SYSTEMRESET(4.8V,SOT-25A) CVIPST8448NR_A 1
IC748 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC751 - I.C,CPU(2M/PLQP0144KA-A) CVIR5F56108VNFP 1
IC751┗
943243102100D R5F56108VNFP
(
MAIN CPU for CX870
)
E3 E3 CVIANAM1896AV 1 *
IC751┗
943243102110D R5F56108VNFP
(
MAIN CPU for CX870
)
E2/E1 E2/E1 CVIANAM1897AV 1 *
IC751┗
943243102120D R5F56108VNFP
(
MAIN CPU for CX870
)
E1C E1C CVIANAM1899AV 1 *
IC751┗
943243102130D R5F56108VNFP
(
MAIN CPU for CX870
)
JP JP CVIANAM1898AV 1 *
IC752 943239101500S I.C,EEPROM(128KBIT,SOP-8P) CVIR1EX24128BSA
S
1*
IC753,754 943239101490S I.C,8-STAGESHIFTREGISTER(TSSOP-16) CVIMC14094BDTR2
G
2*
IC761 963239002150S I.C,OCTALBUFFER/DRIVER CVISN74LVC244AP
W
1
IC771 00D2623077900 I.C,HEXINVERTER E3 HVITC74VHCU04FT 1
IC772 943236101350D I.C,DIR/DIT(WITHADC,LQFP-48P) CVIPCM9211PTR 1
IC773 - I.C,CPLD(TQFP-100P) CVI5M80ZT100C5N 1
IC773┗
943243102270S I.C,PLD
(
AVR-S700W/X1100WALL
)
CVIANAM1901AV 1 *
IC774,775 00D2623198902 I.C,QUAD2-CHANNELMUX(TSSOP-16) HVITC74VHC157FT 2
IC781 943245100360D I.C,DSP(LQFP-176P/350M) CVIADSP21487KSW 1
IC782 - I.C,SERIALFLASH(16M) CVIMX25L1606EM2I
-
1
IC782┗
943248102700S I.C,DSPSerialFlash
(
AVR-S700W/X1100WALL
)
CVIANAM1900AV 1 *
IC783 943246101030S I.C,64MDRAM(54P) CVIA3V64S40GTP-6
0
1*
IC791 943239101080S I.C,DAC(8CH,HTSSOP-48) CVIPCM1690DCAR 1
IC792-795 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 4
IC802 23671011050AS I.C,IPODAUTHENTICATIONFROMD&M CVI23671011050AS
_
1
IC804 943239101520S I.C,0-BITBUFFER/DRIVERTSSOP24TEXASINSTRUMENTS CVISN74LVC827AP
W
1*
IC805 943239100690S I.C,2CHDAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC806 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC811 963236101380P I.C,HDMIBUFFER CVIAD8195ACPZ 1
IC821 943235100520S I.C,INPUTWITH8CHVOLUME(52PLQFP) CVINJU72340AFH3 1
IC851 90M-HC109850R I.C,VIDEO2CH X1100E3 CVIBD3812F 1
IC852 943232100380S I.C,DUALOPAMP(SOP-8P) X1100E3 CVINJM8080G 1
IC881 90M-HC109700R I.C,VIDEOS/W(JRC) CVINJM2595MTE1 1
Q7101,7102 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q7111,7112 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q7121,7122 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q7201-7203 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 3
Q7301,7302 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q7311,7312 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q7403 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7404 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7405 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7406 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7407 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7408 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7409 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7410 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7411 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7412 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7413 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7414 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7415 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7416 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7417 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q7418 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7419 943214500020S T.R,2SC3052 CVT2SC3052 1
Q7420 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q7421 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7422 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q7423 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7501 943214500030S T.R,MUTE CVTINC2001AC1 1
Q7502,7503 943214500020S T.R,2SC3052 CVT2SC3052 2
Q7601-7604 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 4
Q7605-7607 943214500020S T.R,2SC3052 CVT2SC3052 3
Q8001 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q8101 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q8102 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C 1
Q8201 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8202 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8203 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8205 943214500030S T.R,MUTE CVTINC2001AC1 1
Q8501 943215500030S T.R,RT1P441C(47K-47K) X1100E3 CVTRT1P441C 1
Q8502 943216500050S T.R,RT1N441C(47K-47K) X1100E3 CVTRT1N441C 1
Q8503 943215500030S T.R,RT1P441C(47K-47K) X1100E3 CVTRT1P441C 1
Q8506,8507 943214500030S T.R,MUTE X1100E3 CVTINC2001AC1 2
RESISTOR GROUP
8

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
