Denon AVR-S700W Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R7101 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7102 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7103-7105 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 3
R7106-7108 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R7111 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7112 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7113-7115 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 3
R7116-7118 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R7121 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7122 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7123-7125 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 3
R7126-7128 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R7131 nsp RES,CHIP(1608/1%/510ohm) CRJ10DF5100T 1
R7132,7133 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R7134 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7135,7136 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 2
R7137 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7138 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R7139-7141 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 3
R7142 nsp RES,CHIP(1005/5%/1Mohm) CRJ06IJ105T 1
R7143 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7144 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7147 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7149 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7150,7151 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 2
R7152,7153 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R7154 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R7201,7202 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R7203 nsp RES,CHIP(1608/1%/1.6Kohm) CRJ10DF1601T 1
R7204 nsp RES,CHIP(1608/1%/2Kohm) CRJ10DF2001T 1
R7205,7206 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R7207 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7209 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7211-7213 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 3
R7215-7222 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 8
R7223,7224 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R7225 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7227 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7228 nsp RES,CHIP(1608/5%/390Kohm) CRJ10DJ394T 1
R7229 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7230,7231 nsp RES,CHIP(1005/1%/1Kohm) CRJ06IF1001T 2
R7232 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7233 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7234 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7235-7237 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 3
R7239 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7241 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7243-7246 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 4
R7247,7248 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 2
R7249-7251 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 3
R7252 nsp RES,CHIP(1005/5%/2.2Kohm)
CRJ06IJ222T 1
R7253 nsp RES,CHIP(1005/5%/8.2Kohm) CRJ06IJ822T 1
R7254 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7255-7258 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
R7301 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7302 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7303-7305 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 3
R7306-7308 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R7311 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7312 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7313-7315 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 3
R7316-7318 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R7331,7332 nsp RES,CHIP(1608/1%/510ohm) CRJ10DF5100T 2
R7333-7338 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 6
R7339 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7341 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7342 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7343-7345 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 3
R7346 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7349 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7350 nsp RES,CHIP(1005/5%/1Mohm) CRJ06IJ105T 1
R7351 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7352 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7354 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7356 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R7358,7359 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 2
R7360-7362 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R7363,7364 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 2
R7365 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7366,7367 nsp RES,CHIP(1608/1%/51ohm) CRJ10DF51R0T 2
R7368 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7369 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7401 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7402,7403 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7404 nsp RES,CHIP(1608/1%/348Kohm) CRJ10DF3483T 1
R7405 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7406 nsp RES,CHIP(1608/1%/76.8Kohm) CRJ10DF7682T 1
R7411 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7412,7413 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7414 nsp RES,CHIP(1608/1%/348Kohm) CRJ10DF3483T 1
R7415 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7416 nsp RES,CHIP(1608/1%/160Kohm) CRJ10DF1603T 1
R7421 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7422,7423 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7424,7425 nsp RES,CHIP(1608/1%/348Kohm) CRJ10DF3483T 2
R7431 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7432,7433 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7434 nsp RES,CHIP(1608/1%/348Kohm) CRJ10DF3483T 1
R7435 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7436 nsp RES,CHIP(1608/1%/412Kohm) CRJ10DF4123T 1
R7441 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7442,7443 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7444 nsp RES,CHIP(1608/1%/348Kohm) CRJ10DF3483T 1
R7445 nsp RES,CHIP(1608/1%/39Kohm) CRJ10DF3902T 1
R7446 nsp RES,CHIP(1608/1%/300Kohm) CRJ10DF3003T 1
R7451 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
9

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
