Denon AVR-S700W Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R7771-7781 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 11
R7801 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7802-7804 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 3
R7805 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R7806 nsp RES,CHIP(1608/5%/390ohm) CRJ10DJ391T 1
R7807-7810 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 4
R7811,7812 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R7813 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7815,7816 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 2
R7817 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7818 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7819 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7820-7823 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 4
R7824,7825 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R7826 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7827 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7828 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7829 nsp RES,CHIP(1608/5%/4.7Kohm) S700 CRJ10DJ472T 1
R7830 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7831 nsp RES,CHIP(1005/5%/4.7Kohm) X1100 CRJ06IJ472T 1
R7832 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7833 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R7834 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7836 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7838-7841 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 4
R7842-7845 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 4
R7847 nsp RES,CHIP(1005/5%/10ohm) CRJ06IJ100T 1
R7848 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7850 nsp RES,CHIP(1005/5%/10ohm) CRJ06IJ100T 1
R7851,7852 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R7853 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7855 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7857-7859 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 3
R7901 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7902 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7903,7904 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R7907,7908 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R7911,7912 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 2
R7913 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7914 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7915 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7916 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7917 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7918 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7919 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7921,7922 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 2
R7923 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7924 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7925,7926 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R7927 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7928 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7929 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7931,7932 nsp RES,CHIP(1608/0.5%/15Kohm)
CRJ06DD153TP 2
R7933 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7934 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7935 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7936 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7937 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7938 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7939 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7941,7942 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 2
R7943 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7944 nsp RES,CHIP(1608/0.5%/39Kohm) CRJ06DD393TP 1
R7945,7946 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R7947 nsp RES,CHIP(1608/0.5%/39Kohm) CRJ06DD393TP 1
R7948 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7949 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7951,7952 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 2
R7953 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7954 nsp RES,CHIP(1608/0.5%/18Kohm) CRJ06DD183TP 1
R7955 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R7956 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7957 nsp RES,CHIP(1608/0.5%/18Kohm) CRJ06DD183TP 1
R7958 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R7959 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7961,7962 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 2
R7963 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7964 nsp RES,CHIP(1608/0.5%/18Kohm) CRJ06DD183TP 1
R7965,7966 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 2
R7967 nsp RES,CHIP(1608/0.5%/18Kohm) CRJ06DD183TP 1
R7968 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7969 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7971,7972 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 2
R7973 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7974 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7975 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7976 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7977 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7978 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7979 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7981,7982 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 2
R7983 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7984 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7985,7986 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R7987 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7988 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7989 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8001 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8002 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8003-8005 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 3
R8006 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8010 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8011 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8013,8014 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R8015-8017 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 3
R8021,8022 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
11

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
