Denon AVR-S700W Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R8026-8028 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R8041 nsp RES,CHIP(1005/5%/10ohm) CRJ06IJ100T 1
R8055 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8057 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8058 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8060 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8061,8062 nsp RES,CHIP(1005/5%/470ohm) CRJ06IJ471T 2
R8063,8064 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R8074 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R8076 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8077 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R8102 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R8103 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T 1
R8104 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R8105 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8107 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R8108 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8111 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R8117,8118 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R8120,8121 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R8123 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R8126,8127 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T 2
R8128 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8201,8202 nsp RES,CHIP(1608/5%/270ohm) CRJ10DJ271T 2
R8203 nsp RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R8204 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8205 nsp RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R8206 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8207 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8208 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R8209 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8213,8214 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R8215,8216 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 2
R8217,8218 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R8219,8220 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 2
R8221 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8222-8228 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 7
R8229-8231 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R8236-8239 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
R8240,8241 nsp RES,M-OXIDEFILM(1W/150ohm) CRG1SANJ151RT 2
R8242-8244 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
R8245,8246 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R8247-8254 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 8
R8255 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R8256 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8257,8258 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R8259 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8260 nsp RES,CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8261 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8263,8264 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R8265,8266 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R8267 nsp RES,CHIP(1608/5%/220ohm)
CRJ10DJ221T 1
R8271 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8501,8502 nsp RES,M-OXIDEFILM(1W/470ohm) X1100E3 CRG1SANJ471RT 2
R8503,8504 nsp RES,CHIP(1608/5%/100Kohm) X1100E3 CRJ10DJ104T 2
R8505,8506 nsp RES,CHIP(1608/5%/100ohm) X1100E3 CRJ10DJ101T 2
R8507,8508 nsp RES,CHIP(1608/5%/47Kohm) X1100E3 CRJ10DJ473T 2
R8509,8510 nsp RES,CHIP(1608/5%/2.2Kohm) X1100E3 CRJ10DJ222T 2
R8511,8512 nsp RES,CHIP(1608/5%/11Kohm) X1100E3 CRJ10DJ113T 2
R8513,8514 nsp RES,CHIP(1608/5%/100ohm) X1100E3 CRJ10DJ101T 2
R8515 nsp RES,CHIP(1608/5%/10Kohm) X1100E3 CRJ10DJ103T 1
R8516 nsp RES,CHIP(1608/5%/1Kohm) X1100E3 CRJ10DJ102T 1
R8517 nsp RES,CHIP(1608/5%/470Kohm) X1100E3 CRJ10DJ474T 1
R8518 nsp RES,CHIP(1608/5%/10Kohm) X1100E3 CRJ10DJ103T 1
R8521 nsp RES,CHIP(1608/5%/10Kohm) X1100E3 CRJ10DJ103T 1
R8522-8525 nsp RES,CHIP(1608/5%/470ohm) X1100E3 CRJ10DJ471T 4
R8526-8529 nsp RES,CHIP(1608/5%/100Kohm) X1100E3 CRJ10DJ104T 4
R8530,8531 nsp RES,CHIP(1608/5%/220ohm) X1100E3 CRJ10DJ221T 2
R8801,8802 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 2
R8803 nsp RES,CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R8804 nsp RES,CHIP(1608/1%/82ohm) CRJ10DF82R0T 1
R8805 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8806,8807 nsp RES,M-OXIDEFILM(1W/270ohm) CRG1SANJ271RT 2
R8808 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
RN711 nsp RES,CHIP(1005/5%/33ohm*2) CRJ062IJ330T 1
RN712 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN731-733 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 3
RN734 943113100000S COMMONMODEFILTER(1210,90ohm) CLZ9Z188Z 1 *
RN735 nsp RES,CHIP(1005/5%/10ohm*4) CRJ064IJ100T 1
RN761 nsp RES,CHIP(1005/5%/33ohm*2) CRJ062IJ330T 1
RN762 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN765 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN766 nsp RES,CHIP(1005/5%/33ohm*2) CRJ062IJ330T 1
RN767,768 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 2
RN769 nsp RES,CHIP(1005/5%/33ohm*2) CRJ062IJ330T 1
RN781-784 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 4
RN785,786 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T 2
RN787-790 nsp RES,CHIP(1005/5%/10ohm*4) CRJ064IJ100T 4
RN791 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN801 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN802,803 nsp RES,CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T 2
RN805,806 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 2
RN811-814 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 4
CAPACIITORS GROUP
C7101-7105 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 5
C7106 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7107 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7108 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7109 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7110 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7111 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7112 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7113-7130 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 18
C7131 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C7132-7137 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 6
C7138 nsp CAP,CHIP(1608,50V/15pF,C0G)_SAMSUNG CCUS1H150JAS 1
12

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
