Denon AVR-S700W Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C7139 nsp CAP,CHIP(1608,50V/12pF,C0G)_SAMSUNG CCUS1H120JAS 1
C7140-7142 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 3
C7143,7144 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 2
C7145,7146 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C7147,7148 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7153,7154 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7157,7158 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7163,7164 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7166,7167 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7169,7170 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7180,7181 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7190,7191 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7201-7208 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 8
C7209 nsp CAP,ELECT(10V/100uF)-S CCEA1AKS101T 1
C7210 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7211 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7212 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7213 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7214 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7215 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7218 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7219 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7222-7225 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 4
C7226 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7227 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7228 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7229 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7232-7234 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 3
C7235 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C7236-7238 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 3
C7239 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7240 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7242 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7243-7251 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 9
C7278,7279 nsp CAP,CHIP(1608,50V/15pF,C0G)_SAMSUNG CCUS1H150JAS 2
C7301-7304 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 4
C7305 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7306 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7307 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7308 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7309 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7310 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7311 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7312-7328 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 17
C7329 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C7330-7336 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 7
C7337 nsp CAP,CHIP(1608,50V/15pF,C0G)_SAMSUNG CCUS1H150JAS 1
C7338 nsp CAP,CHIP(1608,50V/12pF,C0G)_SAMSUNG CCUS1H120JAS 1
C7339-7341 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 3
C7342-7345 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 4
C7348,7349 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7354,7355 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7357,7358 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7360,7361 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7370,7371 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7380,7381 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C7386 13405014440AS CAP,ELECT(50V/100uF) CCEA1HH101T 1
C7387 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7399,7400 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 2
C7401 00D9430103905 CAP,ELECT(16V/470uF) CCEA1CH471T 1
C7403 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7405 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7406 00D9430103905 CAP,ELECT(16V/470uF) CCEA1CH471T 1
C7409 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7410 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7411 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7412 nsp CAP,CHIP(1608,50V/3.3pF,C0G)_SAMSUNG CCUS1H3R3JAS 1
C7413 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7414 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7415 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7416 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7417 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7420 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7421 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7422 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7423 nsp CAP,CHIP(1608,50V/5pF,C0G)_SAMSUNG CCUS1H050CAS 1
C7424 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7425 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7426 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7427 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7428 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7431 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7432 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7433 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7434 nsp CAP,CHIP(1608,50V/5pF,C0G)_SAMSUNG CCUS1H050CAS 1
C7435 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7436 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7437 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7438 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7439 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7442 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7443 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7444 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7445 nsp CAP,CHIP(1608,50V/5pF,C0G)_SAMSUNG CCUS1H050CAS 1
C7446 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7447 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7448 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7449 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7450 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7453 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7454 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7455 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7456 nsp CAP,CHIP(1608,50V/5pF,C0G)_SAMSUNG CCUS1H050CAS 1
C7457 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7458 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7459 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
13

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
