Denon AVR-S700W Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C7460 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7461 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7464 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7465 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7466 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7467 nsp CAP,CHIP(1608,50V/5pF,C0G)_SAMSUNG CCUS1H050CAS 1
C7468 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7469 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7470 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7471 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG CCUC0J226KCS 1
C7472 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7477 nsp CAP,CHIP(1005,25V/0.022uF,X7R)_SAMSUNG CCUI1E223KCS 1
C7478-7491 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 14
C7492 nsp CAP,CHIP(1005,25V/0.015uF,X7R)_SAMSUNG CCUI1E153KCS 1
C7493 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7494 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7497 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7498 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C7501,7502 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C7503,7504 nsp CAP,CHIP(1608,50V/27pF,C0G)_SAMSUNG CCUS1H270JAS 2
C7505 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7506 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7507-7514 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 8
C7516 nsp CAP,CHIP(1005,50V/220pF,C0G)_SAMSUNG CCUI1H221JAS 1
C7517-7519 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 3
C7520-7523 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 4
C7601 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7603-7605 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG CCUI1E103KCS 3
C7701,7702 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C7704 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG E3 CCUI1E103KCS 1
C7705,7706 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG E3 CCUI1C104KCS 2
C7707,7708 nsp CAP,CHIP(1608,50V/4700pF,X7R)_SAMSUNG CCUS1H472KCS 2
C7709,7710 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C7711 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7712 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C7713,7714 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C7715 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C7716,7717 nsp CAP,CHIP(1608,50V/12pF,C0G)_SAMSUNG CCUS1H120JAS 2
C7718 nsp CAP,CHIP(2012,50V/4700pF,MURATAGRM21) CCUMUC1H472JAM 1
C7719 nsp CAP,CHIP(3216,50V/0.068uF,MURATAGRM31) CCUMUP1H683JAM 1
C7720 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7721 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C7722 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7723 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C7724 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7725 13405014440AS CAP,ELECT(50V/100uF) CCEA1HH101T 1
C7726,7727 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C7751-7758 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 8
C7798-7800 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 3
C7801-7803 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 3
C7804,7805 nsp CAP,CHIP(1608,50V/18pF,C0G)_SAMSUNG CCUS1H180JAS 2
C7806-7841 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 36
C7843 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7845 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C7846,7847 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C7848 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C7849 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7850 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C7851 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7852,7853 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 2
C7854 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7855 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C7856 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7857 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C7858 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7859-7896 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 38
C7901 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7902 943134501780S CAP,ELECT(KR1,47uF/63V,8X11.5) CCEA1JKR1470T 1
C7903 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C7904 943134501780S CAP,ELECT(KR1,47uF/63V,8X11.5) CCEA1JKR1470T 1
C7905 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7906 943134502350S CAP,ELECT(50V/470uF) CCEA1HH471E 1
C7907 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C7908-7910 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 3
C7911 nsp CAP,CHIP(1608,50V/1800pF,X7R)_SAMSUNG CCUS1H182KCS 1
C7913,7914 nsp CAP,CHIP(1608,50V/270pF,C0G)_SAMSUNG CCUS1H271JAS 2
C7916 nsp CAP,ELECT(63V/100uF) CCEA1JH101E 1
C7921 nsp CAP,CHIP(1608,50V/1800pF,X7R)_SAMSUNG CCUS1H182KCS 1
C7923,7924 nsp CAP,CHIP(1608,50V/270pF,C0G)_SAMSUNG CCUS1H271JAS 2
C7926 nsp CAP,ELECT(63V/100uF) CCEA1JH101E 1
C7931 nsp CAP,CHIP(1608,50V/1800pF,X7R)_SAMSUNG CCUS1H182KCS 1
C7933,7934 nsp CAP,CHIP(1608,50V/270pF,C0G)_SAMSUNG CCUS1H271JAS 2
C7941 nsp CAP,CHIP(1608,50V/1200pF,X7R)_SAMSUNG CCUS1H122KCS 1
C7943,7944 nsp CAP,CHIP(1608,50V/150pF,C0G)_SAMSUNG CCUS1H151JAS 2
C7951 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C7953,7954 nsp CAP,CHIP(1608,50V/180pF,C0G)_SAMSUNG CCUS1H181JAS 2
C7961 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C7963,7964 nsp CAP,CHIP(1608,50V/180pF,C0G)_SAMSUNG CCUS1H181JAS 2
C7971 nsp CAP,CHIP(1608,50V/1800pF,X7R)_SAMSUNG CCUS1H182KCS 1
C7973,7974 nsp CAP,CHIP(1608,50V/270pF,C0G)_SAMSUNG CCUS1H271JAS 2
C7981 nsp CAP,CHIP(1608,50V/1800pF,X7R)_SAMSUNG CCUS1H182KCS 1
C7983,7984 nsp CAP,CHIP(1608,50V/270pF,C0G)_SAMSUNG CCUS1H271JAS 2
C7991,7992 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C7993,7994 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C7995-8000 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 6
C8001-8004 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 4
C8005 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8012 nsp CAP,CHIP(1005,25V/0.022uF,X7R)_SAMSUNG CCUI1E223KCS 1
C8018 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8021,8022 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C8023-8028 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 6
C8051-8053 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 3
C8054 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C8055,8056 nsp CAP,CHIP(1608,6.3V/2.2uF,X7R)_SAMSUNG CCUS0J225KCS 2
C8057 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8059 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
14

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
