Denon AVR-X3100W Service Manual

YES
YES
YES
YES
YES
YES
The circuit around Bluetooth Module (iBT-06-02S) or CX870 is faulty.
Can a voltage (5V) be conrmed between pin 1 and pin 4 of BN111 on
DIGITAL PCB?
Can a voltage (5V) be conrmed pin 10 of CN916 on Bluetooth PCB?
Can a voltage (3.3V) be conrmed pin 6 of CN916 on Bluetooth PCB?
Can a voltage (3.6V) be conrmed pin 1 of IC923 on Bluetooth PCB?
Can a waveform (32.768kHz) be conrmed pin 4 of IC922 on Blue-
tooth PCB?
Is 1pin(LDO_ON) of Bluetooth PCB CN916 "Hi"?
The circuit between the AC inlet and BN111 is faulty.
Check the SMPS PCB.
The circuit between BN111 of the DIGITAL PCB and
CN916 of the Bluetooth PCB are faulty of wire or
board.
The circuit around Q1071 or U1070 of the DIGITAL
PCB is faulty.
The circuit around IC923 is faulty.
The oscillation circuit including IC922 is faulty.
The circuit between CX870 and CN916 of the LDO_
ON are faulty.
NO
NO
NO
NO
NO
NO
5.2. Cannot connect to the Bluetooth
102

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
