Denon AVR-X3100W Service Manual

DISASSEMBLY
• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read
"Precautions During Work"
before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the
work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT PCB
(Ref. No. of EXPLODED VIEW : C1)
FRONT HDMI FFC CABLE PCB
(Ref. No. of EXPLODED VIEW : C4)
F.HDMI PCB
(Ref. No. of EXPLODED VIEW : C5)
BLUETOOTH PCB
(Ref. No. of EXPLODED VIEW : C42)
TOP COVER
MAIN TRANS
See "DISASSEMBLY"
8. MAIN TRANS
and "EXPLODED VIEW"
MAIN TRANS
(Ref. No. of EXPLODED VIEW : C21)
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
GUIDE L(12630) PCB
(Ref. No. of EXPLODED VIEW : C7)
GUIDE R(12630) PCB
(Ref. No. of EXPLODED VIEW : C8)
AMP PCB
(Ref. No. of EXPLODED VIEW : C9)
GUIDE FFC PCB
(Ref. No. of EXPLODED VIEW : C11)
DIGITAL PCB ASSY
See "DISASSEMBLY"
3. DIGITAL PCB ASSY
and "EXPLODED VIEW"
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : C15)
CX870 MIDDLE PCB
(Ref. No. of EXPLODED VIEW : P20)
CX870 MODULE
(Ref. No. of EXPLODED VIEW : C18)
Module,NetworkedMedia
(Ref. No. of EXPLODED VIEW : C17)
VIDEO PCB ASSY
See "DISASSEMBLY"
5. VIDEO PCB ASSY
and "EXPLODED VIEW"
VIDEO PCB
(Ref. No. of EXPLODED VIEW : C14)
INPUT PCB ASSY
See "DISASSEMBLY"
4. INPUT PCB ASSY
and "EXPLODED VIEW"
INPUT PCB
(Ref. No. of EXPLODED VIEW : C12)
SPK PCB ASSY
See "DISASSEMBLY"
6. MAIN PCB ASSY
and "EXPLODED VIEW"
SPK PCB
(Ref. No. of EXPLODED VIEW : C33)
FUSE PCB
(Ref. No. of EXPLODED VIEW : C31)
FRT CNT PCB
(Ref. No. of EXPLODED VIEW : C30)
SIDE CNT PCB
(Ref. No. of EXPLODED VIEW : C32)
SMPS PCB
See "DISASSEMBLY"
7. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
(Ref. No. of EXPLODED VIEW : C22)
11

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
