1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
Hold down buttons "
DIMMER
" and "
STATUS
" at the same time and press the power button to turn on the power.
Press the "
STATUS
" button after this to show the information in section 1.3 on the display.
b
A version list is also displayed on GUIs while the version appears on the display.
1.3. Display Order
Error information(See "
1.4. Error display
") →
q
Model destination information →
w
Serial Number
→
e
Firmware Package Version →
r
Main µ-com →
t
Main 1st Boot Loader →
y
Sub µ-com Version
→
u
Sub 1st Boot Loader →
i
DSP ROM →
o
Audio PLD →
Q0
Video PLD →
Q1
GUI SFLASH
→
Q2
Ethernet 1st Boot Loader, Hardware ID →
Q3
Ethernet 2nd Boot Loader, Rhapsody Flag
→
Q4
Ethernet IMAGE →
Q5
Ethernet MAC ADDRESS information →
Q6
BT MAC Address information
q
Model destination information :
FLD
A V R - X 3 1 0 0 W E 3 *
FLD
A V R - X 3 1 0 0 W E 2 *
FLD
A V R - X 3 1 0 0 W E 1 C *
w
Serial Number :
FLD
S / N . * * * * * * * * * *
e
Firmware Package Version :
FLD
P a c k a g e : * * * *
r
Main µ-com Version :
FLD
M a i n : * * * * # # # # *
*
：
Main version,
#
：
Sub version
t
Main 1st Boot Loader :
FLD
M a i n F B L : * * . * *
y
Sub µ-com Version :
FLD
S u b : 6 8 1 Z * * * *
Z
：
Region(E3=1, E2=2, E1C=5),
*
：
version
u
Sub 1st Boot Loader :
FLD
S u b F B L : * * . * *
i
DSP ROM :
FLD
D S P : * * . * *
o
Audio PLD :
FLD
A u d i o P L D : * * . * *
Q0
Video PLD
FLD
V i d e o P L D : * * . * *
20
