Denon AVR-X3100W Service Manual

NO
NO
NO
Is IC901 (TOP256YN) damaged?
Are there the damage in IC901 and
D9001 / D9002 / D9003 / D9004 /
C9004?
Repair the short circuited area(s) by the
soldering of the PCB.
Check the damage of each part.
Replace the damaged part(s).
Replace the damaged part(s).
Has a fuse (F9001) broken?
Are there any short circuits caused by
the soldering of the PCB?
Are any parts damaged?
Replace the IC901 (TOP256YN) and
D9001 / D9002 / D9003 / D9004.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
6. SMPS
105

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
