Denon AVR-X3100W Service Manual

BK903
CMD1A629
OPTION
OPTION
OPTION
OPTION
AC220~240V : 100uF/400V AC100~120V : 220uF/200V
HEATSINK
(16*16*30)
or CHASSIS
HEATSINK
(16*16*25)
AC100 ~ 120V
AC220 ~ 240V
OPTION
OPEN
CCQF2E104KZE-T
R9004 330K(0.2W)
C9006
0.047uF(1608)
C9007
0.01uF(1608)
C9008
0.1uF(1608)
C9010
0.1uF(1608)
R9006
1M(1608)
D9006 1N4007
D9005 1N4007
D9001 1N4007
D9002 1N4007
D9003 1N4007
D9004 1N4007
CX902
0.1uF/275V
R9015
8.2K(1608)
R9016
1K(1608)
R9014
270K(1608)
R9010
1M(0.2W)
R9008
2.2M(0.2W)
ZD908
120V/5W
R9009
2.2M(0.2W)
ZD911
150V/5W
C9012
1000P/1KV
R9017
6.8(0.2W)
C9017
47/25V(NXA)
D9013
1N4007S
ZD920
39V
C9016
0.1uF(1608)
D9008
1N4007
ZD918
22V
C9009 50V/10UF(NXA)
D9009
1N4007
C9018 0.1uF(1608)
C9019 4.7uF(1608)
C9020 5600uF/6.3V
C9021 5600uF/6.3V
C9022 5600uF/6.3V
C9028
2200P 250V
C9029
0.1uF(1608)
1
3
2
D9012
CVDSRL3060P
C9002 0.01uF
250V
C9003
0.01uF 250V
R9030
OPEN(1608)
C9030 OPEN(1608)
C9004
400V/100uF
R9035
1M(2125)
R9036
1M(2125)
R9037
1M(2125)
43
2 1
IC902
PC123Y22
ZD921
7.5V
J9002
JUMPER
J9003
JUMPER
D
G
S
Q9001
INK0010AC1
1
2
3
4
5
6
7
8
10
11
T9001
ZD922
39V
D
7
F S C X V
5 4 3 2 1
IC901
TOP256YN
C9031
OPEN
GND91
OPEN
After primary side rectification
(Caution: High voltage, electric shock)
Primary drain
(Caution: High voltage, electric shock)
After secondary rectifications
A B
C
Operation waveform for each part
A B C
A B C
SMPS unit
(Unloaded)
Set
106

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
