Denon AVR-X3100W Service Manual

4. VIDEO PCB
Proceeding : TOP COVER → BACK CHASSIS → DIGITAL PCB → VIDEO PCB
(1) Remove the connector wire.
5. INPUT PCB
Proceeding : TOP COVER → BACK CHASSIS → DIGITAL PCB → VIDEO PCB → INPUT PCB
(1) Remove the connector wire.
Front side
BN28B
BN27B
BN21B
CUT
PCB HOLDER
Front side
BN26B
BN64C
BN23C
CN706A
TO CN461
CUT
16
