Denon AVR-X3100W Service Manual

2. PANEL / REMOTE LOCK Selection Mode
2.1. Actions
Turn the PANEL LOCK and REMOTE LOCK modes on and off.
2.2. Starting up
Hold down buttons "
TUNER PRESET CH+
" and "
ZONE2 SOURCE
" at the same time and press the power button to turn
on the power.
Select the mode using the button "
TUNER PRESET CH+
", and press the button "
STATUS
" to commit the selection.
2.3. Displaying and Selecting Each Mode
The information shown on the display changes each time the button "
TUNER PRESET CH+
" is pressed.
Press the button "
STATUS
" to set the currently displayed mode and restart the device.
The On/Off setting for each mode is shown by an asterisk "
b
".
q
FLD
F P / V O L L O C K * O N
The buttons on the unit and the master volume knob cannot be operated.
w
FLD
F P L O C K O N
The buttons on the unit cannot be operated.
e
FLD
F P L O C K O F F
The PANEL LOCK mode is turned off.
r
FLD
R C L O C K O n
The device cannot be operated by the remote control.
t
FLD
R C L O C K * O F F
The REMOTE LOCK mode is turned off.
24

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
