Denon AVR-X3100W Service Manual

3.5.6. Audio system conrmation items
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Analog
A 0 1 : A N A L O G P A S S
Input Source : CBL/SAT
Input Mode : ANALOG(xed)
Sound mode : DIRECT
Amp assign : Surround Back
ZONE2 : OFF
・Analog input ⇒ Speaker output (FRONT L,R)
・Analog input ⇒ Preout output (FRONT L,R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
2
Digital
(MAIN ZONE)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL(xed)
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
ZONE2 : OFF
・ Digital input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Digital input ⇒ Preout output (Front L/R, Center, Subwoofer1/2, Surround L/R, Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
3
Digital (signal) Path
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : NETWORK
Input Mode : Auto
Sound mode: STEREO
Amp assign : ZONE2
ZONE2 : ON
ZONE2 Source : Source
・Digital(PCM) input ⇒ Speaker output (Surround Back L/R)
・Digital(PCM) input ⇒ Preout output (ZONE2 L/R)
(
b
As the input source, you can switch from NETWORK to other ones.)
4
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI(xed)
Sound mode: STEREO
Amp assign : Surround Back
ZONE2 : OFF
・HDMI Input ⇒ Speaker output (Front L/R)
・HDMI Input ⇒ Preout output (Front L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
5
A/D
(MAIN ZONE)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog(xed)
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
ZONE2 : OFF
・ Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Analog input ⇒ Preout output (Front L/R, Center, Subwoofer1/2, Surround L/R, Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
6
Amp Assign
(Amp Assign : ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Amp assign : ZONE2
ZONE2 : ON
ZONE2 Source : Source
・Analog input ⇒ Speaker output (Surround Back L/R)
・Analog input ⇒ Preout output (ZONE2 L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
7
Amp Assign
( Amp Assign :
5.1ch (Bi-Amp)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : (Bi-Amp)
ZONE2 OFF
・Analog input ⇒ Speaker output (Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
8
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Front Height
ZONE2 OFF
・Analog input ⇒ Speaker output (Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
9
Front Wide
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Front Wide
ZONE2 OFF
・Analog input ⇒ Speaker output (Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.09
g.10a
g.10b
g.11a
g.11b
g.11c
g.12a
g.12b
g.12c
g.13a
g.13b
g.14
g.15a
g.15b
g.16a
g.16b
g.17a
g.17b
29

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
