Denon AVR-X3100W Service Manual

Input
COMPONENT
C
Check the set value of each
IC. Are the voltage values as
follows?
DIGITAL PCB
BN21A - 4pin : Lo(0V)
BN21A - 3pin : Hi(3.3V)
Is the power supply voltage
being output correctly?
V+5V : C5107 : + side
V-5V : C5109 : - side
Is a signal being output from
the video amplier?
BN21B 15PIN : J5032
COMP-CB : J5008
COMP-CR : J5009
The circuit between IC516
and JK513 are faulty.
Use the jigs to extend the
DIGITAL PCB.
The DIGITAL PCB is faulty.
Check the connection between the
SIDE CONNECTOR PCB and the
VIDEO PCB.
NO
NO
NO
YES
YES
YES
b
All parts are VIDEO PCB parts unless otherwise specied.
w
q
e
r
•Check the IC516 power supply voltage and check the soldering of the surrounding
circuits.
•The circuit between IC516 and JK512 are faulty.
•Check the cable between the unit and the player, and check the player itself.
94

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
