q Power operation button (X)
This turns the power of MAIN ZONE on/o (standby) (vpage55).
w Power indicator
This is lit as follows according to the power status:
•Power on : Green
•Normal standby : O
•When “HDMI Pass Through” (vpage 163) or “HDMI Control”
(vpage163) is set to “On” : Red
•When “IP Control” (vpage189) is set to “Always On” : Red
e Door
When you are using buttons and/or connectors behind the door,
press the bottom of the door to open it. When not using buttons and/
or connectors behind the door, close it. Be careful not to catch your
fingers when closing the door.
r MASTER VOLUME knob
This adjusts the volume level (vpage56).
t Display
This displays various pieces of information (vpage16).
y Remote control sensor
This receives signals from the remote control unit (vpage8).
u SOURCE SELECT knob
This selects the input source (vpage55).
q w
tyu r
e
