Denon AVR-X4000 User Manual

62
Appendix
TipsSettingsConnections
Contents
Front panel Display Rear panel IndexRemote
Playback
Playing files stored on USB memory
devices
1
Connect the USB memory device to the USB port
(vpage46).
2
Press iPod/USB to switch the input source to “iPod/
USB”.
Folder1
Folder2
Folder3
Music1
Music2
Music3
Music4
OPTION
USB [1/9]
Option
3
Use ui to select the file to be played, then press ENTER.
Playback starts.
Operation buttons Function
1
Playback
3
Pause
2
Stop
8 9
Previous / Next
6 7
(Press and hold)
Fast-reverse / Fast-forward
z
ENTER
Playback / Pause
(Press and hold)
Stop
ui
Previous / Next
(Press and hold)
Fast-reverse / Fast-forward
z
CH/PAGE df
Page previous / Page next
z This function is available while an MP3 / WAV / AAC / FLAC file is being played
back.
%
•When an MP3 music file includes album art data, the album art can be displayed
while playing the file.
NOTE
•Note that Denon will accept no responsibility whatsoever for any problems arising
with the data on a USB memory device when using this unit in conjunction with
the USB memory device.

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
