Denon AVR-X4000 User Manual

35
Appendix
TipsSettingsPlayback
Contents
Front panel Display Rear panel IndexRemote
Connections
2 Connecting an external power amplifier
•You can use this unit as a pre-amp by connecting an external power amplifier to the PRE OUT connectors. Adding an external power amplifier with
a higher power output rating than this unit may be beneficial with loudspeakers that have lower eciency and/or lower impedances, or to reach
higher volume levels.
•Select the terminal to use and connect the device.
SIGNAL
GND
AC IN
AM
LOOP
ANT.
COAX.
75Ω
FM
CBL/
SAT
MEDIA
PLAYER
MEDIA
PLAYER
MEDIA
PLAYER
ZONE2
1 CBL
/
SAT
2 DVD
Y
P
B
/
CB
DVD
2
1
3
MONITOR
/
ZONE2
PR
/
CR
PB
/
CB
Y
P
R
/
CR
Denon Link HD
CBL
/
SAT
AUDIO
TV
CD
DVD
COAXIAL OPTICAL
1
1
2
2
DIGITAL AUDIO
IN
DC12V
150mA
MAX.
STRAIGHT CABLE
1
2
RS-232C REMOTE CONTROL
IR
IN OUT
TRIGGER OUT
ARC
1 CBL/SAT
2 DVD
3 Blu-ray
6 AUX24 GAME
5 MEDIA PLAYER
ZONE2
MONITOR1
MONITOR2
PHONO
3 Blu-ray
4 MEDIA PLAYER
1 CBL
/
SAT
2 DVD 5 CD
ANTENNA
NETWORK
MONITOR
IN
COMPONENT VIDEO
VIDEO VIDEO
(
ASSIGNABLE
)
(
ASSIGNABLE
)
(
ASSIGNABLE
)
HDMI
IN
HDMI
OUT
OUT
OUT
(
ASSIGNABLE
)
COMPONENT VIDEO
IN
IN
AUDIO
IN
AUDIO
(
ASSIGNABLE
)
OUT
AUDIO
ASSIGNABLE
FRONT WIDE
FRONT WIDE
FRONT HEIGHT
FRONT HEIGHT
FRONT
FRONT
SURROUND
SURROUND
CENTER
SURROUND BACK
SURROUND BACK
SPEAKERS
IMPEDANCE : 6～16 Ω CLASS 2 WIRING
ASSIGNABLE
ZONE2 ZONE3 FRONT SURROUND FRONT HEIGHT FRONT WIDE CENTER SURROUND BACK
SUBWOOFER
1 2
PRE OUT
L
L
L
L
L
L
R R R
RR R
L
L
L
L
R R
R R
CENTER SURROUND
BACK
RL
SURROUND
RL
FRONT
RL
AUDIO
SUB-
WOOFER
2
AUDIO
SUB-
WOOFER
1
AUDIO
FRONT
WIDE
RL
FRONT
HEIGHT
RL
Subwoofer
(Primary)
Power amplifier
Subwoofer
(Secondary)
%
•When using just one surround back speaker, connect it to the
left channel (L) terminal.

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
