152
Appendix
TipsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Settings
2 Low Frequency Eects
Adjust the low-frequency eects level (LFE).
–10dB – 0dB (Default)
%
•For proper playback of the dierent sources, we recommend setting to the
values below.
•Dolby Digital sources : 0dB
•DTS movie sources : 0dB
•DTS music sources : –10dB
2 Center Gain
Distributes the dialogue output from the center channel to the front left
and right channels and widens the sound image in the front.
0.0 – 1.0
%
•You can set this when the sound mode is set to DTS NEO:X.
•The smaller the value, the more dialogue is concentrated on the center
channel. The larger the value, the more dialogue is distributed to front left and
right channels, and the more the sound image widens in the front.
2 Panorama
Assign front L/R signals to also go to the surround channels for wider
sound.
On : Set.
O (Default) : Do not set.
%
•You can set this when the sound mode is Dolby PLg/gx in the “Music” mode.
2 Dimension
Shift sound image center to front or rear to adjust playback balance.
0 – 6 (Default : 3)
%
•You can set this when the sound mode is Dolby PLg/gx in the “Music” mode.
•As you set a smaller number, the surround sound field shifts backward; as you
set a larger number, the surround sound field shifts forward.
To Next Page
