Denon RCD-M40

To CD playback
2.2. DAB TUNER input (EK model only)
OK
Check control signal for DAB TUNER.
INPUT PCB
• [CN62] : 15, 16 pin
DAB_DATA , DAB_CLK
Check Analog Audio Data output from DAB TUNER.
INPUT PCB
• [DAB TUNER] output
• [CN62] : 24 pin SPDIF
Check Analog Data input to Function IC.
INPUT PCB
• [IC51] : 28 pin DIR
Check Power Supply Voltages for DAB TUNER PCB.
INPUT PCB
• SW+5V
• DAB+3.3V [CN62] : 2 pin
• DAB+1.2V [CN62] : 1 pin
Check soldering.
• [BN94] : 1 pin SW+5V on INPUT PCB
• POWER PCB
• [IC61, IC62] on INPUT PCB
Check parts.
• [IC61, IC62] on INPUT PCB
Check soldering.
• [BN62] : 16, 17 pin on INPUT PCB
• [CN62] on DIGITAL PCB
• [IC11] on DIGITAL PCB
Check soldering.
• [CN62] on INPUT PCB
Check soldering.
• [IC51] on INPUT PCB
NG
NG
NG
NG
OK
OK
OK
35
