Denon RCD-M40

INPUT
1
INPUT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model EK : DAB model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D402-404 943204500410S DIODE, SCHOTTKY CVD1SR159-200H 3
D405 943204006840S DIODE, SCHOTTKY(40V/3A) CVDSS34SR 1
D501,502 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 2
D504 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D506 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D509-511 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 3
D601 943209001080S DIODE , CHIP , SWITCHING EK CVD1SS355T 1
IC42 00D2630810008 I.C REGULATOR HVINJM7808FA 1
IC43 943239101470S I.C DC to DC (4A , 8Pin,SOIC) CVINR111E 1
IC51 943236101350D I.C , DIR/DIT(WITH ADC,LQFP-48P) CVIPCM9211PTR 1
IC52 943239100690S I.C , 2CH DAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC53 00D2623727904 I.C , 2CH VOLUME CVINJW1194V 1
IC55,56 943219500160M I.C, REGULATOR(1.0A, 3.3V, SOT-223) CVILM1117S33 2
IC57 00D9430005605 I.C , REGULATOR (+8V) HVIKA78L08AZT 1
IC58 943231101250D IC , REGULATOR (-8V, TO-92, TAPPING) CVILM79L08TA 1
IC59 23281004250AS I.C , Dual Audio OPAMP(SOP-8) CVINJM8068G 1
IC61 231310009508S I.C , REGULATOR (3.3V) EK
CVIPQ033DNA1ZPH
1
IC62 00D9630300605 IC LM1117S-1.2V SOT223 EK CVILM1117S12 1
Q501 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 1
Q502,503 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 2
Q504 943215500140D T.R,RT1P144C(10K-47K) CVTRT1P144C 1
Q505 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q601 943216500020S T.R,RT1N141C(10K-10K) EK CVTRT1N141C 1
RESISTOR GROUP
R410 nsp RES, CHIP(1608/5%/100Kohm)
CRJ10DJ104T 1
R411 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R413 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R414 nsp RES, CHIP(1608/5%/6.2Kohm) CRJ10DJ622T 1
R415 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R503 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R506 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R507 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R508-515 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 8
R516 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R517 nsp RES, CHIP(1608/5%/1ohm) CRJ10DJ1R0T 1
R518 nsp RES, CHIP(1608/5%/680ohm) CRJ10DJ681T 1
R519,520 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R521-524 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 4
R525-527 nsp RES, CHIP(1608/5%/33ohm) E3, E2, E1C, JP CRJ10DJ330T 3
R532-535 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
R536,537 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 2
R538-540 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R541,542 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R543 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R544,545 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R546 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R552 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T 1
R554,555 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 2
R556,557 nsp RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T 2
R558 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R559 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R560
nsp RES, CHIP(1608/5%/51ohm) CRJ10DJ510T 1
R561 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R562 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R563 nsp RES, CHIP(1608/5%/51ohm) CRJ10DJ510T 1
R565 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R567 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R568,569 nsp RES, CHIP(1608/5%/220Kohm) CRJ10DJ224T 2
R578,579 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 2
R580,581 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R600 nsp RES, CHIP(1608/5%/33ohm) EK CRJ10DJ330T 1
R601, 602 nsp RES, CHIP(1608/5%/0ohm) EK CRJ10DJ0R0T 2
R603 nsp RES, CHIP(1608/5%/47Kohm) EK CRJ10DJ473T 1
RN51-54 90M-BW000470R RES, CHIP(1608/5%/0ohm*4) CRJ104DJ0R0T 4
CAPACIITORS GROUP
C405-407 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C410 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C411 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C412 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C413 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C414,415 nsp CAP, CHIP(3216, 25V/10uF) CCUSSP1E106KC 2
C416 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CCUC1H104KCS 1
C419-421 nsp CAP, CHIP(2012, 25V/22uF, X7R) CCUC1E226KC 3
C422 nsp CAP, CHIP(2012, 50V/0.01uF, X7R)_SAMSUNG CCUC1H103KCS 1
C423,424 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CCUC1H104KCS 2
C425 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C426 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C427 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C428
nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C429 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C430 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C431-433 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C434 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C435 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C436 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C437,438 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 2
C501-503 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C504 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C515 00D2544693900 CAP, ELECT(50V/22uF,ELNA/RFO) CCEA1HRFO220T 1
C516 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C517 00D2544693900 CAP, ELECT(50V/22uF,ELNA/RFO) CCEA1HRFO220T 1
C518,519 nsp CAP, CHIP(3216, 50V/0.1uF, MURATA GRM31)
CCUMUP1H104JAM 2
C520 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C521,522 nsp CAP, CHIP(3216, 50V/0.1uF, MURATA GRM31)
CCUMUP1H104JAM 2
C523,524 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C531 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C532 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C534 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C535 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C536 nsp CAP, ELECT(16V/10uF)-S CCEA1CKS100T 1
C537 nsp CAP, ELECT(16V/10uF) CCEA1CH100T 1
C538 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C539 nsp CAP, ELECT(16V/10uF)-S CCEA1CKS100T 1
C540,541 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C542 00MOA22601620 CAP, ELECT(16V/22uF) CCEA1CH220T 1
