Denon RCD-M40

MAIN
3
MAIN PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model EK : DAB model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D701-705 00D9430182609 DIODE , SWITCHING CVD1SS133MT 5
D706,707 00D9430182502 DIODE , RECT CVD1N4003ST 2
D708 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D709 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25 1
D710 943203500560S DIODE , BRIDGE(600V/10A) CVDD10SB60 1 *
D711-713 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 3
D801 00D9430106203 L.E.D , 2COLOR(RED/GREEN) HVDSPR39MVW3 1
D802-811 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 10
D901 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D902 00D9430209400 DIODE , RECT CVD1N4003SRT 1
D903 90M-HD302280R DIODE , ZENER(CHIP,6.8V) HVDUDZS6.8BSR 1
D904,905 00D9430209400 DIODE , RECT CVD1N4003SRT 2
D906,907 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 2
D908,909 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25 2
D910,911 00D9430209400 DIODE , RECT CVD1N4003SRT 2
D912 90M-HD302440R DIODE , ZENER ,1/2W, 4.7V CVDZJ4.7BT 1
D913 943209001080S DIODE , CHIP , SWITCHING E3, JP CVD1SS355T 1
D914 943202500460D DIODE , ZENER(CHIP,15V) E3, JP HVDUDZS15BSR 1
D915 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D916 00D9430209400 DIODE , RECT CVD1N4003SRT 1
D917 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D918,919 943204500490S DIODE , SCHOTTKY CVD21DQ06T 2 *
D920-923 00D9430209400 DIODE , RECT CVD1N4003SRT 4
D924-929 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T
6
D930 90M-HD302270R DIODE , ZENER(CHIP,5.6V) HVDUDZS5.6BSR 1
D931,932 943202001360S DIODE , ZENER ,1/2W, 20V CVDZJ20BT 2
D933,934 00D9430209400 DIODE , RECT CVD1N4003SRT 2
D935-941 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 7
IC71 943239100850D I.C, HYBRID AMP (2-channel class AB) CVISTK433-060N 1
IC91 943239010400S I.C, REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC92 00D2630641002 I.C , REGULATOR HVINJM7912FA 1
IC93 23281004250AS I.C , Dual Audio OPAMP(SOP-8) CVINJM8068G 1
IC94 943239101670S I.C , Regulator(LDO, 12V ,1A /TO-220F-4) CVINJM2388F12 1 *
Q701 00MHT600141B1 T.R HVTKTA1271YT 1
Q702 00MHT800951B1 T.R HVTKTC3203YT 1
Q703 00MHT600141B1 T.R HVTKTA1271YT 1
Q704 00MHT800951B1 T.R HVTKTC3203YT 1
Q705 943215500140D T.R,RT1P144C(10K-47K) CVTRT1P144C 1
Q706,707 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 2
Q708 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 1
Q709 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q710 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 1
Q711 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q712 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q713,714 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 2
Q715,716 943215500140D T.R,RT1P144C(10K-47K) CVTRT1P144C 2
Q717 90M-HX800030R T.R , CHIP , SOT-23 HVTKRC114S 1
Q718 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
Q719-722 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 4
Q801 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q901 943219006820S
T.R CVTKTC1027YT 1
Q902 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 1
Q903 963216500060S T.R,RT1N144C(10K-47K) E3, JP CVTRT1N144C 1
Q904 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
Q905 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 1
Q906-910 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 5
Q911 943219006820S T.R CVTKTC1027YT 1
RESISTOR GROUP
R701 nsp RES, CARBON(1/5W,1.5Kohm,J) CRD20TJ152T 1
R702-705 nsp RES, CARBON(1/5W,12ohm,J) CRD20TJ120T 4
R706 nsp RES, CARBON(1/5W,1.5Kohm,J) CRD20TJ152T 1
R707 nsp RES, CARBON(1/5W,27Kohm,J) CRD20TJ273T 1
R708 nsp RES, CARBON(1/5W,3.9Kohm,J) CRD20TJ392T 1
R709,710 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T 2
R711 nsp RES, CARBON(1/5W,1.5Kohm,J) CRD20TJ152T 1
R712-715 nsp RES, CARBON(1/5W,12ohm,J) CRD20TJ120T 4
R716 nsp RES, CARBON(1/5W,1.5Kohm,J) CRD20TJ152T 1
R717 nsp RES, CARBON(1/5W,27Kohm,J) CRD20TJ273T 1
R718 nsp RES, CARBON(1/5W,3.9Kohm,J) CRD20TJ392T 1
R719,720 nsp RES, CARBON(1/5W,100ohm,J) CRD20TJ101T 2
R721,722 nsp RES, CARBON(1/5W,300ohm,J) CRD20TJ301T 2
R723,724 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R725,726 943124500510S RES, FLAME RETARDANT (1W/100ohm)
CRG1SANCJ101RTP
2 *
R727 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R728 nsp RES, CARBON(1/5W,820ohm,J) CRD20TJ821T 1
R729 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R730 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R731 nsp RES, CARBON(1/5W,22Kohm,J)
CRD20TJ223T 1
R732 nsp RES, CARBON(1/5W,820ohm,J) CRD20TJ821T 1
R733,734 nsp RES, CARBON(1/5W,27Kohm,J) CRD20TJ273T 2
R735 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R736 nsp RES, CARBON(1/4W,2.7Kohm,J) CRD25TJ272T 1
R737 943129500920M RES , CEMENT CRF5EKR22 1
R738 943121006200M RES , CARBON CRD25FJ4R7T 1
R739 943124500040S RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R740,741 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R742 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R743 nsp RES, CARBON(1/4W,2.7Kohm,J) CRD25TJ272T 1
R744 943124500040S RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R745 943129500920M RES , CEMENT CRF5EKR22 1
R746 943121006200M RES , CARBON CRD25FJ4R7T 1
R747,748 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 2
R749,750 nsp RES, CHIP(1608/5%/270ohm) CRJ10DJ271T 2
R751 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R752 nsp RES, CHIP(1608/5%/82Kohm) CRJ10DJ823T 1
R753,754 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 2
R755 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R756 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R757 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R760 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R761,762 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R763 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R764,765 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 2
R766 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T 1
R767,768 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 2
