Denon RCD-M40

MAIN
5
REF No. Part No. Part Name Remarks Q'ty New Ver
C815,816 nsp CAP, CHIP(1608, 50V/4700pF, X7R)_SAMSUNG CCUS1H472KCS 2
C817-819 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 3
C820,821 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C822 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1
C826 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C828 nsp CAP, ELECT(16V/100uF)-S CCEA1CKS101T 1
C829 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C830,831 943139001280S CAP,METAL-FILM(100V/0.01uF) CCME2A103JXT 2
C832-834 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C835 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C836 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C837 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C838 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C901 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C902,903 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C904 943134502120D CAP, ELECT(TOSHIN, UTSP, 25V/2200uF), 85'C) CCEA1EUTSP222E 1
C905 943134502130D CAP, ELECT(TOSHIN, UTSP, 25V/1000uF, 85'C) CCEA1EUTSP102E 1
C906,907 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C908,909 943134502140D CAP, ELECT(TOSHIN, UTSP, 16V/220uF), 85'C) CCEA1CUTSP221T 2
C910,911 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C912 nsp CAP, ELECT(50V/4.7uF) CCEA1HH4R7T 1
C913 00MOA22705020 CAP, ELECT(50V/220uF) CCEA1HH221E 1
C914,915 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 2
C916,917 nsp CAP , ELECT(63V/100uF) CCEA1JH101E 2
C918 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C919 943134502120D CAP, ELECT(TOSHIN, UTSP, 25V/2200uF), 85'C) CCEA1EUTSP222E 1
C920 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C921 00D2544693939 CAP, ELECT(50V/100uF, ELNA/RFO) CCEA1HRFO101T
1
C922 nsp CAP, ELECT(50V/4.7uF) CCEA1HH4R7T 1
! C924 00D9430024408 CAP , CERAMIC(X1/Y2/SC) KCKDKS472ME 1
C925 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C926,927 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C928 nsp CAP, ELECT(50V/0.68uF) CCEA1HHR68T 1 *
C929 nsp CAP, ELECT(16V/2200uF) CCEA1CH222E 1
C930 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C931 nsp CAP, ELECT(50V/10uF) E3, JP CCEA1HH100T 1
C932 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C933 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C934 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C935 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C936 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C937 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C938 nsp CAP, ELECT(6.3V/1000uF) CCEA0JH102T 1
C939 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C940-945 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 6
C946 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C947 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C948 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C949 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C950 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C951 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C952 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C953 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C954 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C955 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C956 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C957 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C958 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C959 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C960-963 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 4
C991-994 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 4
C997 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C998 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
OTHER PARTS GROUP
BN71 nsp WIRE ASS'Y(7P, 180MM, 2MM PITCH) CWB2B90718047 1 *
BN73 nsp WAFER/ANGLE/2.5mm/11P CJP11GB03ZY 1 *
BN74 nsp WIRE ASS'Y (7P, 80mm, Flat Type ) CWB2B907080G7 1
BN75 nsp WIREASS'Y(7P,100mm) CWB2B90710047 1
BN76 nsp WIRE ASS'Y (5P, 150mm, Flat Type ) CWB1C905150G7 1
BN77 nsp WAFER, FFC(19P-1mm, ANGLE) CJP19GB113ZY 1
BN96 nsp PIN SOCKET (11P,1.25mm,ANGLE,B-TO-B) CJP11HJ282Z 1
BN99 nsp WIRE ASS'Y(3P, 120MM, 2MM PITCH) CWB1D90312047 1 *
CN71,72 nsp LOCKING TYPE , STRAIGHT WAFER , 2MM CJP07GI236ZW 2
CN73 nsp WIRE ASS'Y CWB1C911100BM 1
CN75 nsp WAFER (7P LOCK ANGLE 2.0MM) CJP07GJ247ZW 1
CN90 nsp WAFER, FFC(7P-1mm, ANGLE) CJP07GB113ZY 1
CN92 nsp PIN SOCKET (09P,1.25mm,ANGLE,B-TO-B) CJP09HJ282Z 1
CN94 nsp LOCKING TYPE , STRAIGHT WAFER , 2MM CJP07GI236ZW 1
CN95 nsp LOCKING TYPE , STRAIGHT WAFER , 2mm CJP05GI236ZW 1
CN96,97 nsp PIN HEADER (11P,1.25mm,STRAIGHT,B-TO-B) CJP11GI281Z 2
CN99 nsp LOCKING TYPE , STRAIGHT WAFER , 2MM CJP03GI236ZW 1
CW01 nsp WAFER, 2P, 7.92mm CJP02GA89ZY 1
CW02 nsp WAFER/STRAIGHT/2.5mm/8P CJP08GA01ZY 1
CW03 nsp WAFER,YW396-03B(3.96mm) CJP03GA90ZY 1
F901 nsp HOLDER , FUSE KJCFC5S 2
! F901 00D9430212600 FUSE , GLASS TUBE(125V, 2A, 20MM) E3, JP KBA1C2000A4UY 1 2
! F901 943652001740S FUSE(218Series, 250V/1A) E2, EK, E1C KBA2C1000TLEY 1
FL81 943172100160S V.F.D (FUTABA, 16ST103GINK) CFL16ST103GINK 1
GND1,2 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 2
JK72 nsp JACK , BOARD CJJ4M046Z 1
JK81 943643102870S JACK , HEADPHONE (SILVER) CJJ2D003Z 1
JK82 943643103160S JACK , USB, VERTICAL(MFI, A TYPE) CJJ9X023ZT 1 *
L703,704 943115010260S COIL , SPEAKER(0.5uH) CLEY0R5KAK 2
L801,802 nsp FERRITE CHIP BEAD(4516/60R) CLZ9Z014Z 2
L803 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L804,805 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T 2
L901,902 nsp FERRITE CHIP BEAD(4516/60R) CLZ9Z014Z 2
RC81 943262010290S SENSOR , REMOTE/U CRVKSM603TH5B 1
RL71 90M-LY000330R RELAY HSL4A004ZU 1
! RL91 943682100540S RELAY ,DC6V , 1C1P, 0.25W CSL1E007ZE 1 *
S801-807 00D9430004402 SW , TACT CST1A012ZT 7
VR81 943667007540S ENCODER VOLUME CSR2A052Z 1
★ nsp HEAT SINK ASS'Y CMYRCDM40ZA 1 *
★
nsp SINK , HEAT(M40) CMY2A382 1 *
