47
(3) Communications parameters for USB-COM interface
The following settings take effect only when the USB-COM interface is set up.
Items Parameters Defaults Refer to:
Non-acknowledge mode √
Communications protocol
ACK/NAK mode
Section 11.2 (1)
Enable
CTS signal monitor
Disable √
Section 11.2 (2)
None √
Header
STX
ETX
CR √
LF
Terminator
CR LF
Section 11.3 (1)
CTS signal timeout 0.1 to 9.9 s 0.2 s
ACK/NAK response time 0.1 to 9.9 s 1 s
Section 11.2 (1)
(4) Data transmission format and bar code symbologies
Items Parameters Defaults Refer to:
Enable
Prefix transmission
Disable √
Enable
Suffix transmission
Disable √
Section 11.3 (2)
Enable
Data editing
Disable √
Chapter 9
Enable
Transmission of code ID mark
Disable √
Before prefix
Code ID mark position
After prefix √
Type1 (DENSO 1) √
Type2 (DENSO 2)
Type3
Type4
Code ID mark
Type5 (AIM)
Section 11.3 (3)
Enable, in 4 digits
Enable, in 2 digits
Transmission of the number of digits
(not applicable to UPC/EAN codes)
Disable √
Section 11.3 (4)
Enable
Conversion to GTIN format
Disable √
Section 11.3 (5)
: Can be changed only with the configuration software.
