ELECTRONIC GOVERNOR CONTROLLER (ECU Control Panel)
This machine is equipped with an electronic governor.
The control box contains the Electronic governor controller, adjustment switch, & trimmer.
You should not try to adjust the electronic controller for it has already been set in the factory.
(1) Isochronous - Droop Change-Over Switch
This switch is used to select the control characteristic of
the electronic governor.
The governor is set to Droop Control when it is shipped.
For a detailed explanation of how this works, refer to
"5. Operation".
(2) Droop Adjustment Trimmer
This device is used to adjust the Droop (Speed Regulation
Ratio).
