SecurAccess Compact – User Guide 34
12.4. Dialing mode (Tone/Pulse)
The SecurAccess Compact offers the choice of Tone or Pulse dialing. Check whith your operator or
installer before using the unit. Factory setting is Tone dialing.
Setting to modify Code Setting choice
Factory settings are shown in grey
Conf
Dialling mode 0 0 Pulse : 0 – Tone : 1 *9
Pulse dialing mark/break ratio 0 1 Pulse 66/33 ms : 0 60/40 ms : 1 *9
12.5. Loudspeaker volume
For a better comfort, loudspeaker volume can be adjusted to 3 different levels.
Setting to modify Code Setting choice
Factory settings are shown in grey
Conf
Loudspeaker volume 0 6 Low : 0 – Medium : 1 – High : 2
*9
In very noisy environments, an overboost reception level (+10 dB) can be selected. However, this
feature requires an external power supply (see section § 13.3)
12.6. Memory keys storing
The SecurAccess Compact comes with 1 or 2 off-hook/memory buttons. To store the number to be
dialled when depressing one of these buttons, enter the programming mode and proceed as follows:
Setting to modify Code Setting choice
Factory settings are shown in grey
Conf.
M1 Key n°1 (mandatory) 2 0 Number to store (* # = pause) (22 digits max)
Note : no digit entered erases a previous stored number
*9
M1 Key n°2 (mandatory) 2 5 Number to store (* # = pause) (22 digits max)
Note : no digit entered erases a previous stored number
*9
12.7. Chain dialling
This feature, when activated, will automatically keep on dialling a sequence of numbers stored into
the same memory/off-hook button if the other party does not answer or if busy line tone is detected, it
will only stop when another party answers.
Up to 5 different numbers can be stored in each memory and the dialling sequence can be repeated
up to 9 times. Time elapsed before the next call can be adjusted.
Programming this feature can be done locally or remotely.
Each button can store up to 5 numbers but, in order to activate the chain dialling, at least one number
must be stored to in order to repeat the dialling sequence (in case of just one number, this number
only would be repeated).
Example :
Setting to modify Code Setting choice
Factory settings are shown in grey
Conf.
Number 1 Key n°1 (mandatory) 2 0 Number to store (* # = pause) (22 digits max)
Note : no digit entered erases a previous stored number
*9
Number 2 for chain dialling on key n°1 2 1 Number to store (* # = pause) (22 digits max)
Note : no digit entered erases a previous stored number
*9
Number 3 for chain dialling on key n°1 2 2 Number to store (* # = pause) (22 digits max)
Note : no digit entered erases a previous stored number
*9
Number 4 for chain dialling on key n°1 2 3 Number to store (* # = pause) (22 digits max)
Note : no digit entered erases a previous stored number
*9
Number 4 for chain dialling on key n°1 2 3 Number to store (* # = pause) (22 digits max)
Note : no digit entered erases a previous stored number
*9
