16 User Manual | Pedelec with centre motor
3.3.2 Mode buttons
You can speci the power-assist level using the Mode but-
tons. Each time you press a Mode button the power assist
changes by one level.
If you require more assistance, press the Mode button that
points upwards. In the HIGH mode, if you press the Mode
button that points upwards, it goes into the LOW mode.
For less assistance, press the Mode button that points
downwards. In the LOW mode, if you press the Mode but-
ton that points downwards, it goes into the HIGH mode.
3.3.3 Power-assist mode
You can choose to relax and let the bike do the work, exert
yourself more physically, or simply get om A to B as fast
as possible. You can decide this yourself by choosing an
appropriate power-assist mode.
Display LEDS ASSIST LEVEL
HIGH This means the assistance is working
hard.
MID This means the assistance is working
with a medium level of eort.
LOW This means the assistance is working
with a low level of eort.
3.3.4 Battery charge state
A stylised battery divided into ve segments on the dis-
play shows the charge remaining in the battery. The lower
the charge state of the battery is, the fewer segments are
displayed.
DISPLAY BATTERY CHARGE STATE
5 bars light up 80–100%, and for two
seconds when the power is
switched on.
4 bars light up 60-80%
3 bars light up 40-60%
2 bars light up 20-40%
1 bar lights up 10-20%
1 bar ashes <10%
No display 0%
3.3.5 Display button
Press the Display button briey to display the following
consecutively:
• the battery capacity in percent
• the speed in km/h
• the trip in km
• the remaining distance in km.
Instead of km/h (kilometres per hour) you can choose
to display the information in mph (miles per hour).
Miles per hour is the unit of speed typically used in
the UK and US. 0.62 mph is roughly 1 km/h. For this
display, simple press and hold the upper and lower
Mode button.
3.3.5.1 Battery capacity
The battery capacity shows in percent how much more
electrical charge your battery can hold.
3.3.5.2 Speed
The speed shows what your current speed in kilometres
per hour or miles per hour is.
3.3.5.3 Trip
This displays the distance travelled in kilometres or miles.
3.3.5.4 Remaining distance
The remaining distance is displayed in kilometres or
miles. It depends on which mode is currently selected.
The higher the level of assistance, the shorter the remain-
ing distance.
