14-8 SDI-12 Operations XL™ Series
PC Interface View Built In Display Screen
a M - Adrs (a) Measurement Type
Adrs 0 M Type [M ]->
Set the measurement type for the selected address
PC Interface View Built In Display Screen
a P - Adrs (a) Serial Port
Adrs 0 Port[SDI-12]->
Select which port to use for the selected address. SDI-12 commands may be directed out one of
the serial ports instead of the standard SDI-12 port.
PC Interface View Built In Display Screen
a A - Adrs (a) Redirect Option
Adrs 0 Redirect [0]->
Select if the primary address will be redirected to a secondary address. This is used when
multiple measurement types are required for a single sensor.
