16-24 Operation with the GOES Radio XL™ Series
16.4 GOES Random Options
Random transmissions are sent based on some condition such as high water or heavy rain fall.
Several of the option screens use the abbreviation RR to indicate this is a Random mode option.
Random data will always use the pseudo-binary format and the data will be preceded with the
characters “BRT”.
Built in Menu Structure: GOES Random Transmit Options.
GOES Options -> Random Options -> RR Channel: [000]
RR Rate: [00:00:00]
RR Baud Rate = 100
Tx Fnt [0 ]
RR Data Opts -> Source 1 [XXXXXX]
| :
| Source 5 [XXXXXX]
RR Buffer Cnt = 0
Transmit RR Data?
PC Menu Screen: GOES Random Transmit Options.
Random Options (Esc to Return)
C - Channel Number: 000
R - Transmit Rate: 00:00:00
B - Random BaudRate: 100
A - Alarm Condition: 0
T - Transmit Options
F - Force Random Transmission
Buffer Byte Count: 0
Enter Option >
PC Interface View Built In Display Screen
C - Channel Number
RR Channel [000]
This option allows the user to enter the Random transmission channel number. The range is 1 to
199 and represents a specific frequency for communicating with the satellite. The channel
number will be assigned by NESDIS.
