XL™ Series SDI-12 Operations 14-9
14.4 SDI-12 Sensor Mode
The XL™ can be configured as an SDI-12 sensor when used with other data loggers. SDI-12
sensors will have a unique address and will measure between 1 to 9 data values. The options
under this menu allow the user to select what address the XL™ will respond to and what data
will be returned to the external data logger.
Built in Menu Structure: SDI-12 Sensor Mode Options.
System Setup -> Sensor Mode Setup -> Sensor Mode Enabled
Sensor Mode Adrs [X]
SDI Meas. Time = XXX
Par 1 Source[XXXXXX]
:
Par 9 Source[XXXXXX]
Par 1 Digits[2]
:
Par 9 Digits[2]
PC Menu Screen: SDI-12 Sensor Mode Options.
Sensor Mode Setup (Esc to Return)
SDI-12 Sensor Mode Status: Enabled
A - SDI-12 Address: 0
T - Total Measurement Time: 7
1 - Parameter 1: Stage B - Digits: 2
2 - Parameter 2: PSI C - Digits: 2
3 - Parameter 3: PtTemp D - Digits: 2
4 - Parameter 4: None E - Digits: 2
5 - Parameter 5: None F - Digits: 2
6 - Parameter 6: None G - Digits: 2
7 - Parameter 7: None H - Digits: 2
8 - Parameter 8: None I - Digits: 2
9 - Parameter 9: None J - Digits: 2
Enter Option >
PC Interface View Built In Display Screen
