XL™ Series SDI-12 Operations 14-11
PC Interface View Built In Display Screen
1 - Parameter 1: None
Par 1 Source [ None]
Up to nine values may be defined to be measured and sent to the data logger. The default is to
send back the stage, PSI and temperature in that order for the H-350XL. The standard input
source options are available except the SDI-12 sources, time and date, see the list below.
Available Source Options
None This parameter is not used, and all following parameters are ignored.
Stage Use the Stage reading for this parameter. (H-350XL™ Model only)
PSI Use the PSI reading for this parameter. (H-350XL™ Model only)
PtTemp Use the Temperature reading for this parameter. (H-350XL™ Model only)
RemStg Use Remote Stage reading for this parameter. (H-350XL™ Model only)
Counts Use the Counts for this parameter.
TotCnt Use the Total Counts for this parameter.
CtRate Use the Count Rate for this parameter.
AnaX Use analog channel X for this parameter.
DigI/OX Use digital I/O X for this parameter.
Freq Use the frequency reading for this parameter.
Encoder Use the encoder input value for this parameter.
Batt Use the Battery reading for this parameter.
Tscans Use the Tscans reading for this parameter.
BasicX Use the BasicX reading for this parameter.
FNT01 to FNT40 Use the selected user defined math function result for this parameter.
NOTE: When the XL™ is used as a sensor connected to another data logger using the SDI-12
interface, the aD0 command will return data values for parameters 1, 2, and 3, the aD1 command
will return data values for parameters 4, 5, and 6, and the aD2 command will return data for
parameters 7, 8, and 9.
PC Interface View Built In Display Screen
B - Digits: 2
Par 1 Digits [2]
These options allow the user to define how many digits to the right of the decimal will be
returned for each SDI-12 parameter. The default is two, but it may be set between 0 and 6.
