XL™ Series Data Card Options 20-5
After the protocol has been selected a message prompt will be displayed asking if the complete
file or only data from a specified date should be sent.
ASCII Transfer or XModem Transfer (A/X)?
Transmit Complete File or from Selected Date? (C/D)?
If the file transfer protocol is an ASCII transfer, then the following screen will be displayed. The
method to set the file capture options is dependent on the terminal emulation program in use. In
Hyperterm use the mouse to select the ‘Transfer’ option at the top of the window. Then select
the ‘Capture Text’ sub option and follow the prompts for entering a file name on the PC. Once
this is done press the ‘S’ key to start the transfer. The data will scroll across the screen. When it
is done the message ‘Done, Close File’ will be displayed. At this point use the mouse again to
select ‘Trnasfer’ and then select the sub option ‘Capture Text’ and select ‘Stop’. The data will be
stored in the file and directory specified when first setting up the transfer options in windows.
ASCII Transfer or XModem Transfer (A/X)?
Transmit Complete File or from Selected Date? (C/D)?
Set File Capture Options, Press ‘S’ To Start
Any other key to abort
If the file transfer protocol is an XModem transfer, then the following screen will be displayed.
The method to initiate the transfer is dependent on the terminal emulation program in use. In
Hyperterm use the mouse to select the ‘Transfer’ option at the top of the window. Then select
the ‘Receive File’ sub option and follow the prompts for entering a directory and file name on the
PC and selecting the Xmodem protocol. Once this is done use the mouse to select the ‘Start’
button and the transfer will start. A new box will appear showing the status of the transfer.
When it is done the new box will disappear. Press any key to return to the main data options
menu. The data will be stored in the file and directory specified when first setting up the transfer
options in windows.
ASCII Transfer or XModem Transfer (A/X)?
Transmit Complete File or from Selected Date? (C/D)?
Initiate XModem Download Now (Esc to Cancel)
PC Interface View Built In Display Screen
Not Available Using PC Menu
Copy .New To Card ->
This option allows the user to copy the .New file to the data card. Once the copy is complete, the
XL™ will prompt the user to erase the .New file, pressing enter will erase the .New file and
