6159924330 - 08/2020 - 15 -
8 2 x 8 Input/Output connector
9 Fieldbus slot
10 eBUS
11 RS232 port (2 serial ports)
12 4 Ethernet ports
Dimensions
Refer to the CAD 3D models and 2D views available at https://www.desouttertools.com/resource-centre.
Mounting of controllers
WARNING Electrical Hazard
Risk of electrick shock.
► Place the controller in such a way the blue Ground Fault Interruptor located on the controller bottom panel
can be easily switched off.
Install the controllers as shown above or use the following kits below.
