3300-0188-0M Rev L y apex Digital Scale Owner’s 4
4. Position the column over the opening in the scale base and then insert the column
into
the sc
ale base making sure the cable from the column goes out of the scale base an
d
und
er the axle for the wheels.
5. With both cable coming out of the scale base under the axle, align the wire connector
from the column cable with the wire connector from the scale base cable and then plug
the
m together.
Step 4 Step 5
6.
Making sure the column is completely down in the scale base and against the back
plate, tuck the connected cables into the scale base under the axle.
Step 6
7. Using the 3/16” Allen wrench, evenly tighten the (4)
Allen head screws on the back of the scale base to
secure column to scale base
.
NOT
E: The nuts on the front of the column
opening in the scale base may turn as you are
tightening the Allen head screws.
This is normal. DO NOT use a wrench or other
tool to hold the nut to keep it from turning!
Step 7
Both cables must
be under the axle!
