8529-0637-2M Rev C DL Series Owner’s Manual
INSTALLATION
Included in carton:
DL Series Price Computing NTEP legal-for-trade scale
Tray - 2 pcs: plastic tray & metal top
Display pole and screw pack (DL1030P/DL1060P only)
Owner’s Manual
DLX50 DL Series Scale Utility CD
Four (4) overlays for shortcut PLU
Power Cord
Attachment of Tower Display
Remove the cover tower bracket on the bottom of the base. Place the tower display close to
the base. Connect the tower display cable to the circuit board in the base. Gently slide the
tower post into the bracket. Fasten the tower to the base with two bolts provided. Replace
bracket cover.
Placement
Place the scale in an environment free of excessive dust and moisture and on a stable,
vibration-free level surface away from direct sunlight and any rapidly moving air source
(heating/cooling vents, fans, etc.). This will prevent sudden temperature changes and air
currents that may result in unstable weight readings.
WARNING! DO NOT place the scale on an unstable cart, stand, or table. The scale
may fall causing injury to the operator, and damage to the unit, or proper operation of
the scale may be inhibited.
Level Adjustment
Check to make certain the scale is level. The level indicator is located at the front of the scale.
If the scale is not level (the bubble will not be centered), adjust the mounting feet as required to
center the bubble, and attain a level scale.
Power Connection
The scale uses an external AC power cord that is to be used in a standard 120 V AC 50/60Hz
grounded wall outlet.
NOTE: The DLX50 DL Series Scale Utility is available for download for users without a
CD drive on their computer. Download the utility from Detecto.com at:
https://detecto.com/resources/softwaredetail/dlx50-dl-series-scale-pc-utility
