19 devolo dLAN pro
devolo dLAN pro 1200+ WiFi ac/n
This configuration ensures that each company has ac-
cess only to its own assigned data traffic even
though all data runs through the same, commonly
used physical network.
2.2.4 Dynamic VLAN
The use of dynamic VLANs (virtual LANs) in Enterprise
WiFi provides a series of advantages for the adminis-
trator and WiFi users.
The following applies to WiFi users:
쎲 The WiFi network (SSID) can be located more eas-
ily, because only one SSID is visible for various
VLANs.
쎲 This provides more bandwidth for payloads within
a WiFi network, because each additional broad-
cast SSID worsens the efficiency of the radio inter-
face.
The following applies to administrators:
쎲 Central assignment of WiFi users to VLANs in the
RADIUS server or an associated directory service.
쎲 Dynamic change to the assignment without inter-
action by the WiFi user.
Here, a standard VLAN can be defined for an SSID. If
the RADIUS server does not provide a VLAN assign-
ment for a user, the user is assigned automatically to
the default VLAN.
If no default VLAN is configured, these users are reject-
ed from using the WiFi access point. Adding a VLAN is
not required for this configuration. Management data
are transmitted untagged and the payloads from us-
ers are given the VLAN tag assigned by the RADIUS.
Fig. 7: Dynamic VLAN

Devolo dlan pro 1200+ wifi ac Specifications

General

Modulation	64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, QPSK
Power plug	Type F
Ethernet LAN	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	128-bit AES
Networking standards	IEEE 1901, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Filter characteristics	-22 - -45 dB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Current	16 A
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (standby)	2.2 W
Power consumption (typical)	8.1 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Cables included	LAN (RJ-45)
Quantity per pack	2 pc(s)

Weight and Dimensions

Depth	76 mm
Width	152 mm
Height	40 mm
Package depth	228 mm
Package width	184 mm
Package height	86 mm
Package weight	830 g
