Devolo dlan pro 1200+ wifi ac User Guide

9 Preface
devolo dLAN pro 1200+ WiFi ac/n
Wireless propertiesfor the 2.4 GHz range Wireless propertiesfor the 5 GHz range
Chan-
nel
Frequency Max. transmitting
power
1 2,412 GHz
2 2,417 GHz
3 2,422 GHz
4 2,427 GHz
5 2,432 GHz
6 2,437 GHz
7 2,442 GHz
8 2,447 GHz
9 2,452 GHz
10 2,457 GHz
11 2,462 GHz
12 2,467 GHz
13 2,472 GHz
Chan-
nel
Frequency Max. transmitting
power
36 5,180 GHz
40 5,200 GHz
44 5,220 GHz
48 5,240 GHz
52 5,260 GHz
56 5,280 GHz
60 5,300 GHz
64 5,320 GHz
100 5,500 GHz
104 5,520 GHz
108 5,540 GHz
560mW/27,5dBm
112 5,560 GHz
100 mW/20 dBm
200mW/23dBm
200mW/23dBm

Devolo dlan pro 1200+ wifi ac Specifications

General

Modulation	64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, QPSK
Power plug	Type F
Ethernet LAN	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	128-bit AES
Networking standards	IEEE 1901, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Filter characteristics	-22 - -45 dB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Current	16 A
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (standby)	2.2 W
Power consumption (typical)	8.1 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Cables included	LAN (RJ-45)
Quantity per pack	2 pc(s)

Weight and Dimensions

Depth	76 mm
Width	152 mm
Height	40 mm
Package depth	228 mm
Package width	184 mm
Package height	86 mm
Package weight	830 g
