DIMAX804KC User’s Manual
8
DEXON Systems
• Recall
• Clear
If you want to store the current layout for future usage, select the Store menu item. An ‘*’ sign
before the Store keyword will show that the given layout contains the arrangement. Any
previously stored layout can be restored by the help of Recall menu item. Select the Clear menu
item if a layout is not needed any more. An ‘*’ sign before Clear keyword shows that the given
layout is empty.
You can use the push buttons (L1-L8) to select certain layouts only if you are not navigating in
the main menu and the Button Function is in Layout mode.
3.1.3
User Presets
User Presets mean set of configuration parameters that include all the input configurations,
output configurations and advanced configurations. The structure of the Presets menu is very
similar to the Layouts menu. The user can do the same operations on each preset:
• Store
• Recall
• Clear
You may save 4 sets of parameters.
3.2
Setup through HTML5 Web Browser
The matrix switcher can be configured and set up by the Web application program. Please
connect this device to a network. LAN Communication format:
6464 (Communication Request Port, TCP/IP)
6465 (Communication Event Port, TCP/IP)
6466 (Communication Request Port, WebSocket)
6467 (Communication Event Port, WebSocket)
80 (HTTP)
