6 SPECIFICATIONS
6.1 Electrical, Mechanics and Environment
Size 435 x 328 x 45 mm
Weight 3200 g
Power supply 100 – 240 V Auto ranging
Dissipation max. 90 W
Cooling cooling controller fan
Operating temperature range
5- 40 degrees centigrade
Operating humidity range
10 – 90% non-condensing
Storage temperature range
-20 - +60 degrees centigrade
Storage humidity range 10 – 90% non-condensing
Altitude 0 – 2000 m
6.2 Input Signals
HDMI signal timings and standards
Mode
Horizontal
Frequency
Pixel
Frequency
Standard
640 x 350 @ 85Hz
37.9 kHz
31.5 MHz
DMT ID 01h
640 x 400 @ 85Hz
37.9 kHz
31.5 MHz
DMT ID 02h
640 x 480 @ 60Hz
31.5 kHz
25.175 MHz
DMT ID 04h
640 x 480 @ 72Hz
37.9 kHz
31.5 MHz
DMT ID 05h
640 x 480 @ 75Hz
37.5 kHz
31.5 MHz
DMT ID 06h
640 x 480 @ 85Hz
43.3 kHz
36.0 MHz
DMT ID 07h
720 x 400 @ 85Hz
37.9 kHz
35.5 MHz
DMT ID 03h
800 x 600 @ 56Hz
35.23 kHz
36.0 MHz
DMT ID 08h
800 x 600 @ 60Hz
37.9 kHz
40.0 MHz
DMT ID 09h
800 x 600 @ 72Hz
48.1 kHz
50.0 MHz
DMT ID 0Ah
800 x 600 @ 75Hz
46.9 kHz
49.5 MHz
DMT ID 0Bh
800 x 600 @ 85Hz
53.7 kHz
56.25 MHz
DMT ID 0Ch
800 x 600 @ 120Hz RB
76.3 kHz
73.25 MHz
DMT ID 0Dh
848 x 480 @ 60Hz
31.0 kHz
33.75 MHz
DMT ID 0Eh
1024 x 768 @ 60Hz
48.4 kHz
65.0 MHz
DMT ID 10h
1024 x 768 @ 70Hz
56.5 kHz
75.0 MHz
DMT ID 11h
1024 x 768 @ 75Hz
60.0 kHz
78.75 MHz
DMT ID 12h
1024 x 768 @ 85Hz
68.7 kHz
94.5 MHz
DMT ID 13h
1024 x 768 @ 120Hz RB
97.6 kHz
115.5 MHz
DMT ID 14h
1152 x 864 @ 75Hz
67.5 kHz
108.0 MHz
DMT ID 15h
1280 x 768 @ 60Hz RB
47.4 kHz
68.25 MHz
DMT ID 16h
1280 x 768 @ 60Hz
47.8 kHz
79.5 MHz
DMT ID 17h
1280 x 768 @ 75Hz
60.3 kHz
102.25 MHz
DMT ID 18h
