Part # 8533-083-001 1/18
Cabinet and Front Panel Group Part # by Model
Large Door
Key Description T900 T1200 QTY
1 Panel, Side (Left or Right) - stainless 9454-839-001 9454-814-001 4
* Bolt-1/4-20x1/2 (side panel Front to Rear) 9545-018-013 9545-018-013 8
Nut 1/4-20UNC (side panel) 8640-414-006 8640-414-006 8
Strap Assy (Side to base) 9966-012-001 9966-012-002 4
* Shim (side panel) 9552-039-001 9552-042-001 2
* Nut, Hex 1/4-20 UNC 8640-414-006 8640-414-006 8
2 Bracket, Side Panel under front panel 9046-085-001 9046-085-001 1
* Screw #10Bx1/2 side panel brkt 9545-008-026 9545-008-026 1
* Nut 1/4-20 UNC side panel brkt 8640-414-006 8640-414-006 1
• Nut, Hex 8640-413-002 8640-413-002 2
* Screw 9545-008-024 9545-008-024 2
3 Panel Assy, Front 9454-840-002 9454-811-002 1
4 Band, Edge Protector 9578-092-002 9578-092-002 1
* Bumper Loading Door 9051-055-001 9051-055-001 1
* Nut, 1/4 x 20 for bumper 8640-414-006 8640-414-006 1
* Screw, Hex- To Control Panel 9545-008-024 9545-008-024 2
* Nut, Spring- To Control Panel 10/32 8640-399-003 8640-399-003 2
5 Screw, Flat Head- Front to Sides 9545-008-014 9545-008-014 2
6 Washer, Finish 8641-585-001 8641-585-001 2
* Nut, Spring-To Front Panel 8640-399-008 8640-399-008 2
7 Label, Door Opening (Black) 8502-757-0 01 8502-757-0 01 1
8 Panel, Control (Mounts Nameplate) 9989-480-001 9989-456-001 1
* Screw, Control Panel to Sides 9545-008-026 9545-008-026 4
9 Nameplate Decal, Control Black 9412-224-001 9412-229-001
10 Panel Top 945 4-736 -001 1
11A Panel Top Front 9454-761-001 1
11B Panel Top Rear 9454-762- 001 1
12 Lock, Top (w/Key) 8650-012-003 8650-012-003 2
13 Door, Lower Service, Includes Handle 9960-286-004 9960-286-004 1
14 Handle (bumper guard) 9244-086-003 9244-086-003 1
* Rivet Blind 3/16” Alum 9491-009-003 9491-009-003 4
* Screw 9545-045-010 9545-045-010 4
To Next Page
