Rear View Access Part # by Model

Key Description T900 T1200 QTY

1 Drive Motor, 3 Phase (Inverter duty) 9376-308-001 9376-329-001 1

2 Rod, Motor Mtg 9497-222-004 9497-222-004 1

* Collar, Shaft (w/set screws) (old) 9076-052-002 9076-052-002 2

* Motor Bushing (plastic) 9053-074-002 9053-074-002 1

3 New motor bushing support 9053-082-001 9053-082-001 2

4 Clamp for motor bushing 8654-117-019 8654 -117-019 2

5 Pulley, Motor 9453-175-002 9453-175-002 1

* Split TaperBushing (motor pulley) 9053-077-001 9053-077-001 2

* Screw taper bushing 1/4-20x1 9545-018-024 9545-018-024 3

6 Bolt, Eye (1/4”-20x1/2”) 9545-055-001 9545-055-001 1

* Nut, 1/4 Elastic Stop 8640-414-003 8640-414-003 1

* Link (open end) 9341-046-001 9341-046-001 1

7 Chain (Spring Tension) 9099-012-003 9099-012-004 1

8 Spring, Belt Tension 9534-151-000 9534-151-000 1

9 Pulley, Driven 9453-176-005 9453-176-005 1

10 Bolt, 3/8”-16 x 2” 9545-029-011 9545-029-011 3

11 Washer, 3/8” 8641-582-003 8641-582-003 3

* Bushing Taperlock (Driven) 9053-078-002 9053-078-002 1

12 Washer-Flat .675x2-1/2x1/4 8641-581-043 8641-581-043 1

13 Lockwasher-Exttooth, 5/8 8641-582-018 8641-582-018 1

14 Bolt, 5/8-11x1 1/2 9545-060-001 9545-060-001 1

15 Drive Belt 9040-079-002 9040-079-003 1

* Panel Assy., Back 9989-526-001 9545-766- 001 1

* Screw Panel Mtg.#10Bx1/2” 9545-008-026

* Nut, Spring 8640-399-008 8640-399-008 AR

* Screw, To Base-1/4” x 3/4” 9545-030-002 9545-030-002 3

Part # 8533-083-001 1/18
