Front Mount Detergent Dispenser
Top Mount Detergent Dispenser
Key Description T900 T1200 QTY
1 Dispenser Soap 9122-005-004 1
2 Gasket Despinsor 9206-416-001 1
* Hose, Despinsor to tub 9242-450-001 1
* Clamp 8654 -117-008 2
* Nut, Spring ss 8640-399-007 4
* Flow restictors 9475-002-002 2
* Flow restictors Optional (Smaller) 9475-002-003 2
3 Door, Dispenser 9108-095-005 1
4 Pin, Plain 9451-191-001 2
* Post, Door Mounting 9467-025-001 2
6 Screw- 8B x 1/2 9545-045-002 4
Screw, SS Dispenser, 10B x 1 9545-008-012 4
* Washer Flat 5/16 8641-581-008 8641-581-008 1
7 Screw, Locator 9545-008-023 9545-008-023 1
8 Plastic Sleeve, Locator 9355-001-001 9355-001-001 1
* Catch, Top Panel 9086-017-001 9086-017-001 2
* Lock, Top (w/Key) 8650-012-003 8650-012-003 2
Key Description T900 T1200 QTY
9 Bolt,#10-32 x 1 1/4”SS 9545-012-026 6
10 Special Washer, Rubber 8641-222-000 6
* Tub Front 1
11 Washer-Flat, 1/4 8641-581-018 12
12 Nut, #10-32UNF 8640-413-002 6
13 Spacer Plastic #10x1/2 9538-157- 019 6
14 Soap Dispenser (no lid) 9807-087-001 1
* Det. Dispenser Mtg Gasket to Tub frnt 9206-425-001 1
15 Bracket Soap box mounting 9029-122-002 1
16 Nut Hex Elasticstop #10-32 SS mtg dispenser 8640-413-006 6
17 Lid Assembly dispenser 9987-104-001 1
18 Lid screws #10-32x1/2 SS 9545-012-017 2
19 Softner siphon tube (plastic) 9574-252-002 1
* Flow restictors 9475-002-003 AR
20 Washer Dispenser Label Black 8502-756 -001 1
* Kit-Soap Dish, Replacement (Large Door) 9732-290-001
77
Part # 8533-083-001 1/18
77
