Key Description T900 T1200 QTY
1 Channel, Rear 9081-169-001 9081-169-001 1
2 Screw #10Bx1/2 9545-008-026 9545-008-026 4
* Nut, Spring 8640-399-008 8640-399-008 4
3 Plug, 7/8 9456-041-006 9456-041-006 1
4 Bushing, 7/8” 9053-067-002 9053-067-002 1
5 Braacket-Terminal Block Assy 9029-265-001 9029-265-001 1
6 Screw, 10Bx1/2 9545-008-026 9545-008-026 4
7 Strip-Terminal marker, Power 9558-025-001 9558-025-001 1
8 Terminal Block-Power 9897-033-002 9897-033-002 1
* Screw-6ABx3/4 9545-031-010 9545-031-010 2
9 Harness-Power Terminal Block 9627-747-003 9627-747-003 1
10 Terrminal Lug, Solderless 8652-134-001 8652-134-001 1
* Lockwasher-Exttooth, #10 8641-582-006 8641-582-006 1
* Screw-10-32ttX1x1/2Grn 9545-008-027 9545-008-027 2
11 Strip-Terminal Marking, Injector 9558-028-001 9558-028-001 1
12 Terminal Block-Injector 9897-032-002 9897-032-002 1
* Screw-4Bx5/8ss 9545-053-002 9545-053-002 2
13 Harness-Injection 9627-799-0 01 9627-799-0 03 1
14 Label-Warning 8502-639-001 8502-639-001 1
15 Bushing-Insulated, 3/4” 9053-067-001 9053-067-001 1
16 Bushing-Insulated, 1 9053-067-004 9053-067-004 1
* Cover, Terminal Block 9074-267-001 9074-267-001 1
* Screw #10Bx1/2 9545-008-026 9545-008-026 1
17 Plate-Drive mounting 9982-383-001 9982-383-001 1
18 Nut, #10-32UNF, 2B 8460-413-002 8460-413-002 4
19 VFD Delta “E” drive 208-240 volt 9375-028-015 9375-028-013 1
20 Nut, #10-32UNF, 2B 8460-413-002 8460-413-002 4
* Cable, Data 9806-015-001 9806-015-003 1
* Clamp, Cable 8654-125-005 8654-125-005 1
21 Plate-Water Valves, Mounting 9452-814-001 9452-814-001 1
22 Nut, #10-32UNF, 2B 8460-413-002 8460-413-002 4
23 Valve-Water, Duel Coil 9379-183-012 9379-183-012 2
24 Screw #10Bx1/2 9545-008-026 9545-008-026 4
* Plate-Cover, Water Valves 9452-794-001 1
* Screw, 10Bx1/2 9545-008-026 2
25 Water-Valve, Single Coil 9379-194 -001 2
26 Screw-Phillips, 4mx0.7x8mm 9545-064-001 4
27
Shield, Water Valves 9550-195-001 9550-195-001 1
28
Clip-Push 9083-121-001 9083-121- 0 01 4
29
Cap-Injector Assy 0935-127-001 0935-127-001 1
30
Clamp 8654-117- 014 8654-117- 014 1
31
Hose-Suds Overow 9242-463-004 9242-463-004 1
32
Resistors (160 Ohm) 9483-004-003 9483-004-003 2
33 Screws #10-32x1/2” (Mounting) 9545-012-008 9545-012-008 4
34
Jumper Wires 8220 -117-002 8220-117-0 02 2
80
Part # 8533-083-001 1/18
