Chassis and Drain Part # by Model

Key Description T-90 0 T-120 0 QTY

1 Base Assy,Frame 9945-128-002 9945-125-002 1

2 Outer Tub Assy. 9930-157-001 9930-150-001 1

* Tub & Cylinder Assy. 9869-027-003 9869-022-001 1

3 Tub Front 9974-011-001 9974-011-002 1

* Gasket, Tub Front 9206-421-002 9206-421-002 1

4 Ring Assy, Tub Mtg-Front Clamp 9950-055-001 9950-055-001 1

5 Bolt, Top Front Ring 3/8”-16 x 3” 9545-029-009 9545-029-009 1

6 Nut WCAD 3/8”-16 8640-415-001 8640-415-001 1

7 Bolt, 1/2” -13 x 2” Rings to Base 9545-017-013 9545-017-013 2

8 Nut, Wizloc 1/2” x 13 8640-417-005 8640-417-005 2

9 Washer, Flat 1/2” 8641-581-026 8641-581-026 2

10 Hose, Tub to Drain Valve 9242-459-001 9242-459-001 1

11 Clamp, Hose (Tub to Drain Valve) 8654-117-014 8654 -117-014 2

12 Valve, Drain 9379-200-001 9379-200-001 1

* Screw, Valve to Base 1/4ABx3/4 9545-030-002 9545-030-002 2

* Washer, Flat 1/4 8641-581-017 8641-581-017 2

13 Hose, Drain Valve to Tube 9242-457-001 9242-457-001 1

* Clamp, Hose (Drain Valve to Tube 8654 -117-014 8654-117-014 2

14 Tube Assy, Drain 9915-120-004 9915-126-002 1

15 Clamp, Hose (Tube to Frame Bracket) 8654-117- 014 8654-117-014 1

* Bracket, Drain Tube 9029-162-002 1

* Screw Tube (Bracket to Base 1/4Bx3/4) 9545-030-002 9545-030-002 4

16 Hose, Overow Tub To Drain Tube 9242-449-003 9242-449-003 1

* Clamp, Hose 8654-117-018 8654-117-018 2

17 Tube, Suds overow 9242-463-004 9242-463-004 1

* Clamp, Hose 8654-117-008 8654 -117-008 2

18 Hose, Pressure switch 9242-175-0 07 9242-175-00 4 1

Clamp, Hose 8654-117-015 8654-117-015 1

Part # 8533-083-001 1/18
