Dexter Laundry A Series Service Manual

Control Panel Part # by Model
Key Description T900 T1200 QTY
1 Panel Control Assembly(panel only) After Serial
#530673
9989-480-001 9989-456-001 1
2 Nameplate,Control Panel (one piece) Black 9412-224-001 9412-229-001 1
* Screw-Hxwshrhdundct #10Bx 1/2”(Control Panel To
side Panel)
9545-008-026 9545-008-026 4
3 Plastic Shield over main PCB 9550-184-001 9550-184-001 1
4 Nut Hexkeps #8-32 8640-412-005 8640-412-005 3
5 Screw FillHDCR 10Bx1/2” Guide 9545-008-023 9545-008-023 1
6 Locator Panel 9355-001-001 9355-001-001 1
7 Plate -Latch, Top 9452-625-001 9452-625-001 2
8 Nut Hexkeps #8-32 8640-412-005 8640-412-005 4
9 Spacer Pushbutton (Micro) 9538-178-001 9538-178-001 1
10 Pushbutton Control (OPL), Black 9035-060-004 9035-060-004 1
11 Retainer Pushbutton (Micro) 9486-158- 001 9 486-158-001 1
12 Nut Hexelasticstop #4-40 8640-424-002 8640-424-002 2
13 Spacer Plastic #6x9/16 9538-157- 018 9538-157-018 5
14 PCB assembly Control /Display 9473-004-008 9473-004-008 1
15 Nut Elasticstop #6-32 8640-411-002 8640-411-002 4
16 Nut Hexkeps #6-32 8640-411-003 8640-411-003 1
17 Spacer Plastic #6x9/16 9538-157-018 9538-157-018 2
18 PCB assembly Mode lights 9473-005-001 9473-005-001 1
19 Nut Hexkeps #6-32 8640-411-003 8640-411-003 2
20 Harness-LED PCB, P3 9627-797-001 9627-797-001 1
21 Spacer Plastic #6x9/16 9538-157-018 9538-157- 018 2
22 Light, LED,ADD BLEACH Asembly 9794-001-001 9794-001-001 1
23 Nut Hexkeps #6-32 8640-411-003 8640-411-003 2
24 Lock-Run/Program, w/Harness & Key, P2 8650-027-001 8650-027-001 1
* Key (N561) 6292-006-013 6292-006-013 AR
25 Actuator Assy-Door Locking, 120V 9892-015-001 9892-015-001 1
26 Nut Hexkeps #8-32 8640-412-005 8640-412-005 4
27 Nut-Spring 8640-399-008 8640-399-008 2
28 Bracket-Retainer, Front Panel 9029-191-001 9029-191-001 1
29 Screw FillHDCR 10Bx1/2” Guide 9545-008-023 9545-008-023 2
* Harness-Optional relay, P23-P15 9627-798-001 9627-798-001 1
* Harness-PCB to Relay, P8-P16 9627-794-001 9627-794 -001 1
* Harness-Door Lock, P4 9627-791- 005 9627-791-0 05 1
* Harness-PCB to Enable, P20-P21 9627-793-001 9627-793-001 1
* Transformer-120V/24/5.3, P7 8711-009-001 8711-009-001 1
* Harness-Pressure Switch, P5 9627-807-001 9627-807-001
98
Part # 8533-083-001 1/18
