Dexter Laundry A Series Service Manual

Key Description T-900 T1200 QTY
27 Cylinder Assy 9848-136- 001 9848-137-002
* Tub Front 9974-011-001 9974-011-002 1
* Gasket, Tub Front 9206-421-002 9206-421-002 1
* Ring Assy, Tub Mtg-Front Clamp 9950-055-001 9950-055-001 1
* Bolt, Top Front Ring 3/8”-16 x 3” 9545-029-009 9545-029-009 1
* Nut WCAD 3/8”-16 8640-415-001 8640-415-001 1
83
Part # 8533-083-001 1/18
83
11
7
9
8
10
25
19,20
18
21,22,23,24
8
9
11
11 G
8
9
10
5
6
3
12,13
42
1
27
14,15,16,17
