Key Description T900 T1200 QTY
1 Trough Assy,Controls 208-240 volt (all parts below
#2-#43)
9857-216-001 9857-217-001 1
* Trough only 9839-018-001 9839-018-001 1
* Screw, Trough Sides 9545-008-026 9545-008-026 4
* Lockwasher Exttooth #10 8641-582-006 8641-582-006 4
* Angle Support Trough 9003-271-001 1
* Screw, Trough Bracket 9545-008-026 9545-008-026 4
* Channel-Trough Mounting 9081-108-001 9801-110-001 1
* Screw-10Bx1/2 9545-008-026 9545-008-026 4
2 Screw GRN. #10-32x 1/2” 8639-621-007 8639-621-007 1
* Lockwasher #10 8641-582-006 8641-582-006 1
3 Transformer, Control (Secondary Voltage to 115 volts) 8711-004-001 8711-004-001 1
4 Screw, Mtg #8Bx1/4” 9545-045-001 9545-045-001 4
* Lockwasher #10 8641-582-006 8641-582-006 4
5 Terminal Block Assy, POWER 9897-026-004 9897-026-004 1
* Screw, Mtg 8Bx3/8” 9545-045-007 9545-045-007 2
6 Transformer, (Step Down) 120/2.3 VAC&24 VAC 50/60hz 8711-009-001 8711-009-001 1
* Lockwasher #10 exttooth 8641-582-005 8641-582-005 4
7 Screw, Mtg #10Bx1/2” 9545-045-001 9545-045-001 4
8 PCB assembly Relay Main 9473-006-001 9473-006-001 1
* Support-3/8” Edge Holding 9548-285-001 9548-285-001 6
9 Bushing , Wire 7/8 9053-067-002 9053-067-002 2
* Wire Assy, Enable-Yellow 32” 8220-064-023 8220-064-023 2
10 Harness, P17 Drain/Therm/Sol 9627-796-002 9627-796-002 1
11 Harness P19/Water Valve 9627-795-002 9627-795-004 1
* Harness P8/P16 , Control 9627-794-001 9627-794-004 1
12 Harness P20/P21, Enable 9627-793-001 9627-793-001 1
13 Optional Relay board 9473-007-001 9473-007-001 1
14 Support-3/8” Edge Holding 9548-285-001 9548-285-001 4
15 Harness, P10 To Terminal Block 9627-799-001 9627-799-0 01 1
16 Harness, P15/P23 Injection 9627-798-001 9627-798-001 1
17 Switch, Pressure 9539-490-001 9539-490-001 1
18 Harness P5/Pressure 9627-807-001 9627-807-001 1
* Stando Twistlock 9527-002-002 9527-002-002 4
19 Fuse Holder Assy 9200-001-002 9200-001-002 1
* Fuse, 1.5Amp 8636-018-001 1
* Fuse, 2.5Amp 8636-018-004 1
20 Label-Fuse, 1.5Amp 8502-716-001 1
20 Label-Fuse, 1.5Amp 8502-716-002 1
* Terminal Grounding, 8652-130-037 8652-130-037 1
* Screw 10-32 x 1/2 GRN 9545-008-027 9545-008-027 1
* Lockwasher, #10 8641-582-006 8641-582-006 1
* Kit-Pressure Sensor, Electronic 9732-314-001 9732-314-001 1
21 Kit-Repaacement, Pressure Sensor (only) 9732-315-001 9732-315-001 1
* Support-PCB, 3/8”, Edge Holding 9458-285-001 9458-285-001 1
22 Transformer-120/18VAC, 5 VA 8711-015-001 8711-015-001 1
23 Screw, 8B x 1/4 9545-045-001 9545-045-001 1
* Wire Assy BLK/BLU 8220-001-233 8220-001-233 1
* Wire Assy RED/BLU 8220-001-232 8220-001-232 1
96
Part # 8533-083-001 1/18
