SPECIFICATIONS
30 lb. Commercial Stack Dryer: T-30x2 - DC30X2NC-15EC1X (60Hz), DC30X2ND-15EC2X, DC30X2NC-39AC1X
(50Hz)
Cabinet Height 76 1/4” 1937 mm.
(Assumes minimum leveling leg adjustment)
Cabinet Width 31 1/2” 800 mm.
Overall Depth 49 1/2” 1257 mm.
Floor to Bottom of Door - Bottom Dryer 7 5/8” 194 mm.
Floor to Bottom of Door- Top Dryer 57 3/4” 1149 mm.
Door Opening 22 5/8” 575 mm.
Dry Wt. Capacity 30 x 2 lbs. 13.6 x 2 kg.
Cylinder Diameter 30” 762 mm.
Cylinder Depth 27 1/2” 699 mm.
Cylinder Volume 11.25 cu. ft. 319 liters
Lint Screen Area 453 sq. in. 2923 sq. cm.
Gas Input (per dryer- 60 hz) 90,000 Btu/hr 26.4 kW
Gas Input (per dryer- 50 hz) 74,000 Btu/hr 21.7 kW
Gas Supply Connection 1/2” 12.7 mm.
Natural Gas Supply (Water Column) 5-8” 127 mm. - 203 mm.
Natural Burner Manifold 3 1/2” 88.9 mm.
L.P. Supply (Water Column) 11 ½ -14” 292 mm. - 356 mm.
L.P. Burner Manifold 11” 279 mm.
Exhaust Size 8” 203 mm.
Make-up Air 1.5 sq. ft. 1394 sq. cm.
Example: 1.5 sq. ft = 1 ft. long X 1.5 ft. wide
Motor Size 1/2 H.P. .373 kW
Airow (60 hz) 600 CFM 17.0 m^3/min
Airow (50 hz) 500 CFM 14.2 m^3/min
Electrical Specications - 120/60/1
Voltage/Hz/Phase 120V/60Hz/1Phase
Running Amps 8.0
Circuit Protection Amps 20
Wire Size 12 gauge
Electrical Service 2 wire + ground
Electrical Specications - 208-240/60/1
Voltage/Hz/Phase 208-240V/60Hz/1Phase
Running Amps 5.0
Circuit Protection Amps 15
Wire Size 12 gauge
Electrical Service 2 wire + ground
Electrical Specications - 230V/50/1
Voltage/Hz/Phase 230V/50Hz/1Phase
Running Amps 10.0
Circuit Protection Amps 15
Wire Size 12 gauge
Electrical Service 2 wire + ground
Shipping Weight 750 lbs. 340 kg.
Net Weight 699 lbs. 317 kg.
Clearance Behind Machines (min.) 18” 457 mm.
14
Part # 8533-090-001 7/21
